Appleton MLEDN15P5BU Mercmaster Enclosed And Gasketed Luminaire
Part Number # MLEDN15P5BU
SKU # 2430279
$1230.07 / Each
Typical price:$2174.76 / Each
Appleton MLEDN15P5BU Key Features
| Brand: | Appleton |
|---|---|
| Part Number # : | MLEDN15P5BU |
| SKU #: | 2430279 |
| Amperage Rating: | 0.53/0.25 A |
| Color Rendering Index (CRI): | 70 |
| Dimensions: | 15.4 in L x 10.92 in H |
| Enclosure Type: | IP66/IP67 |
| Housing Finish: | Baked Gray Epoxy-Clad |
| Lamp Type: | LED |
| Lamp Wattage: | 61 W |
| Lens Type: | Polycarbonate |
| Lumens: | 4850 Lumens |
| Series: | LED Series |
| Country of origin: | MX |
| Housing material: | Cast Copper Free Aluminum |
| Manufacturer Name: | Emerson Electric |
| UNSPSC: | 39112102 |
| UPC: | 00078138195543 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1230.07 / Each
Typical price:$2174.76 / Each
Quantity:
- Appleton Mercmaster Enclosed and Gasketed Luminaire, Series: LED Series, 120 to 277 V AC, 0.53/0.25 A, 61 W Lamp, 60000 hr Average Life, 5650 K Color Temperature, 70 CRI, Polycarbonate Lens, 4850 Lumens, IP66/IP67 Enclosure, Cast Copper Free Aluminum Housing Material, Baked Gray Epoxy-Clad Housing Finish, 15.4 in L x 10.92 in H Dimensions
MLEDN15P5BU Application
Marine and Wet Locations, Wide Range of Industrial, Chemical Processing and other Areas, Pulp and Paper Mills, Processing Plants, Chemical Plants, Oil Refineries, Foundries, Manufacturing Plants, Storage Areas, Waste and Sewage Treatment and Parking Garages ApplicationsMLEDN15P5BU Item Features
- Compact light weight low profile design is suited for low mounting heights
- Modular design allows scores of fixture component combinations to meet installation needs
- Hinge has high lip for added safety during installation and servicing
- Hinge and bolt construction assures 360 deg compression at all points on ballast housing gasket for positive sealing
- Swing away design of captive bolt and nut simplifies servicing
- NPT and metric threads standard
- NEMA type V symmetrical light distribution
MLEDN15P5BU Standards
CSA C22.2 No. 250|C22.2 No. 137|cCSAus 065182|UL 1598|UL 1598A|UL 8750|UL 844|UL Listed for Class I, Div 2, Groups A, B, C, D, Class I, Zone 2, Group IIC, Class II, Div 1, Group E, F, G, Class II, Div 2, Group F, G, Class IIISKU #2430279Part Number #MLEDN15P5BUUNSPSC39112102UPC00078138195543
