Part Number # 16204-3
SKU # 7268
Image provided may only be a representation of
final product and may include optional equipment
16204-3
Bussmann 16204-3 Power Distribution Block
Part Number # 16204-3
SKU # 7268
Bussmann 16204-3 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | 16204-3 |
| SKU #: | 7268 |
| Amperage Rating: | 175, 175 A |
| Dimensions: | 2.7 in L x 2.88 in W x 1.75 in H |
| Finish: | Tin Plated |
| Number of Poles: | 3 |
| Series: | 162 |
| Short Circuit Current Rating (kA): | 200, 200 kA |
| Type: | Barrier, Barrier Splicer, Barrier/Splicer |
| Wire Size: | 8 to 2/0, 8 to 2/0 AWG Cu/Al Line/Load |
| Country of origin: | MX |
| Material: | Aluminum/Thermoplastic, Thermoplastic |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121629 |
| UPC: | 00051712148658 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann 16204-3 Power Distribution Block
Brand: Bussmann
Part Number: 16204-3
Bussmann Power Splicer Block, Barrier, Series: 162, 600 VAC/VDC, 175 A, 3 Pole, 8 to 2/0 AWG Cu/Al Line/Load Wire, 200 kA Short Circuit Current, Aluminum/Thermoplastic, Tin Plated, Black, 2.7 in L x 2.88 in W x 1.75 in H
Additional Description: BUSS-16204-3 BUSS POWER BLOCK
Catalog Description: Eaton Bussmann series power splicer block, 600 Vac, 600 Vdc, 175 A, Three-pole, SCCR: 200 kA, Black, Molded Thermoplastic Base, Tin-plated aluminum connector
16204-3 Application
Electrical Assemblies, Panels and EOEMs Applications16204-3 Item Features
- 8 to 2/0 AWG copper/aluminum line/load connection
- https://www.youtube.com/watch?v=YMvqUyoETXk
16204-3 Standards
Contact Manufacturer,Contact factory,RoHS CompliantSKU #7268Part Number #16204-3UNSPSC39121629UPC00051712148658
