5BHLE-250E
Bussmann 5BHLE-250E Semiconductor Fuse
Part Number # 5BHLE-250E
SKU # 2415987
$2553.59 / Each
Typical price:$5192.72 / Each
Bussmann 5BHLE-250E Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | 5BHLE-250E |
| SKU #: | 2415987 |
| Amperage Rating: | 250 A |
| Class: | E |
| Indicating/Non-Indicating: | Indicating |
| Interrupt Rating: | 63 kA |
| Series: | BHLE, HLE |
| Type: | 1-Barrel General Purpose Helix, E-Rated |
| Country of origin: | DO |
| Material: | Glass Resin Casing/Silica Sand Filler |
| Mounting type: | Bolt-In/Bolt-On/Clip/Hook Eye, Bolted-In |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121628 |
| UPC: | 00051712528399 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$2553.59 / Each
Typical price:$5192.72 / Each
Quantity:
- EATON Bussmann Current Limiting Fuse, 1-Barrel General Purpose Helix, Series: BHLE, Indicating, 250 A, 5.5 kV, 63 kA Interrupt, Class: E, Bolt-In/Bolt-On/Clip/Hook Eye Mount, Pure Silver Element, Glass Resin Casing/Silica Sand Filler, 15.9 in L x 3 in W x 3 in H Body Size
5BHLE-250E Application
Power, Transformers, Capacitor Banks, Fused Switches and Indoor/Outdoor Applications5BHLE-250E Item Features
- Optimized energy exchange the double concentric helix configuration (inner and outer) optimizes energy exchange by making more efficient use of the sand filler
- Improved arc control the double helix design has more elements for more surface area permitting better arc control
- Lower temperature rise heat radiation with the HLE design is excellent resulting in lower normal operating temperatures
- Promotes faster melting under overload conditions, thermal transfer from the inner helix is reduced by a modified temperature gradient leading to faster melting
- Blown fuse indication blown fuse striker pin will protrude from the top of the fuse providing a visual indication of operation, as well as a triggering means for external devices
- Interchangeability helix type fuses are mechanically interchangeable and in many cases have higher maximum current ratings than competing current limiting fuses
- E-rated power
- Short clip center designs
- Disconnect and non-disconnect mountings, live parts
5BHLE-250E Standards
IEEE C37.41|ANSI SpecifiedSKU #2415987Part Number #5BHLE-250EUNSPSC39121628UPC00051712528399
