Part Number # CGL-125
SKU # 2344030
Image Disclaimers Message
Brand: Bussmann
CGL-125
Bussmann CGL-125 Fuse
Part Number # CGL-125
SKU # 2344030
$423.54 / Each
Typical price:$861.27 / Each
Bussmann CGL-125 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | CGL-125 |
| SKU #: | 2344030 |
| Amperage Rating: | 125 A |
| Body Type: | Cartridge |
| Class: | C |
| Interrupt Rating: | 200 kAIC at 600 VAC, 40 kAIC at 250 VDC, 200/40 |
| Series: | CGL |
| Terminal Type: | Blade, Blade End |
| Type: | HRC Form II Current Limiting Non-Indicating |
| Country of origin: | MX |
| Material: | Fiberglass |
| Mounting type: | Stud |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712100465 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$423.54 / Each
Typical price:$861.27 / Each
Quantity:
- Bussmann Tron Fuse, HRC Form II Current Limiting Non-Indicating, Series: CGL, 125 A, 600 V AC/250 V DC, 200 kAIC at 600 VAC, 40 kAIC at 250 VDC Interrupt, Class: C, Blade End Terminal, Stud Mount, Cartridge Body Type, Dual Element, Fiberglass, 1.5 in Dia x 5.31 in L Body Size
CGL-125 Application
For use with circuits subject to surge currents such as those caused by motors, transformers and other inductive loads Applications, Industrial Facilities and Factory Facilities, Safety and Security SystemsCGL-125 Item Features
- Current limiting HRCII-C fuses designed to withstand inrush currents on typical motor start-ups while offering high current limitation in the short circuit region
- Close sizing to loads allows using smaller and less costly switches
- Provides a higher degree of short circuit protection
- Helps protect motors against burnout from overloads
- https://www.youtube.com/watch?v=YMvqUyoETXk
CGL-125 Standards
CE Certified|CSA C22.2 No. 106SKU #2344030Part Number #CGL-125UNSPSC39121626UPC00051712100465
