Part Number # CH143DIU
SKU # 2392224
CH143DIU
Bussmann CH143DIU Modular Fuse Holder
Part Number # CH143DIU
SKU # 2392224
Bussmann CH143DIU Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | CH143DIU |
| SKU #: | 2392224 |
| Amperage Rating: | 50 A |
| Dimensions: | 225 mm L x 48 mm W x 80 mm H |
| Fuse Diameter: | 14 mm |
| Fuse Length: | 51 mm |
| Number of Poles: | 3 |
| Suitable For Use With: | Standard Cylindrical Fuse-Links and FW Type Ferrule Fuse-Links |
| Temperature Rating (Degrees F): | -20 to 70 deg C |
| Type: | Low Voltage Cylindrical |
| Country of origin: | CN |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121606 |
| UPC: | 00051712685177 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann CH143DIU Modular Fuse Holder
Brand: Bussmann
Part Number: CH143DIU
Bussmann Modular Fuse Holder, Low Voltage Cylindrical, 690 VAC, 50 A, 3 Pole, DIN Rail Mounting, 51 mm Fuse Length, 14 mm Diameter Fuse, -20 to 70 deg C, For Use With: Standard Cylindrical Fuse-Links and FW Type Ferrule Fuse-Links, 225 mm L x 48 mm W x 80 mm H Dimensions
Additional Description: BUSS-CH143DIU 3P 14x51 Neon Indicator Fuse Holder
Catalog Description: Fuse accessory, Fuse-holder, low voltage, 50 A, AC 690 V, 14 x 51 mm, 3P, IEC, with indicator, replaced by CH143BI, C14G fuses, C14M fuses, IEC 60269-1
CH143DIU Application
Electrical Assemblies, Panels and EOEMs - Aftermarket, Panel Builders, Control Panels for Machines, Industrial Facilities and Factories - Power Distribution and ControlCH143DIU Item Features
- Compact dimensions
- Ventilation zones optimized for a better heat dissipation
- Inbuilt padlocking facility
- IP20 degree of protection
- Photovoltaic version rated at 1500 VDC (IEC only) for use with gPV fuse links
- Flexibility to mount on DIN rail and/or screw mounting
- Toolless DIN rail mounting, improves ease of use and reduces installation time and costs
- https://www.youtube.com/watch?v=YMvqUyoETXk
CH143DIU Standards
EAC ,IEC 60269-2 ,UL Listed File E14853 ,IEC 60269-1 ,IEC 60269-2 ,IEC 60269-1 ,UL Listed File E14853 ,EAC ,IEC 60269-1 ,EAC ,UL Listed File E14853 ,IEC 60269-2 ,IEC 60269-1 ,IEC 60269-2 ,EAC ,UL Listed File E14853,RoHS Compliant,CE Marked,CE-Kennzeichnung,RoHS-konform,Zgodny z wymogami RoHS,Uzyskano oznaczenie CE,CE-markering,RoHS-compliantSKU #2392224Part Number #CH143DIUUNSPSC39121606UPC00051712685177
Image provided may only be a representation of final product and may include optional equipment
