Brand: Bussmann
Bussmann FNQ-R-10 Time Delay Fuse
Part Number # FNQ-R-10
SKU # 7601
$52.83 / Each
$77.66/Each
17 In Stock
Ships in 1 Business Day
Bussmann FNQ-R-10 Key Features
Brand: Bussmann
Part Number # FNQ-R-10
SKU #7601
Amperage Rating: 10, 10 A
Body Type: Cylindrical
Class: CC
Indicating/Non-Indicating: Non-Indicating
Interrupt Rating: 200, 200 kAIC
Rejection/Non-Rejection: Rejection
Response Time: 12 s at 200%
Series: FNQ-R
Terminal Type: Ferrule, Ferrule End
Type: Current Limiting, Current Limiting Time Delay
Voltage Rating: 600, 600 V
Country of origin: MX
Material: Melamine, Melamine Tube
Mounting type: Holder
Manufacturer Name: Eaton
UNSPSC: 39121606
UPC: 00051712497091
$52.83 / Each
$77.66/Each
Bussmann FNQ-R-10 Time Delay Fuse
Brand: Bussmann
Part Number: FNQ-R-10
Bussmann Limitron Fuse, Current Limiting Time Delay, Series: FNQ-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 10 A, 600 V, 200 kAIC Interrupt, Class: CC, 12 s at 200% Response, Ferrule End Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Melamine Tube, 13/32 in Dia x 1-1/2 in L Body Size
Additional Description: BUSS-FNQ-R-10 CLASS CC TIME DELAY DELAY
Catalog Description: Eaton Bussmann Series Class CC fuse, FNQ, time-delay, dual-element current limiting fuse, 10 Amp rejection style fuse, interrupting rating of 200kA at 600Vac
FNQ-R-10 Application
Industrial Facilities and Factories, Safety and Security Systems, Branch Circuits, Line Protection and Small Control Transformers ApplicationsFNQ-R-10 Item Features
- Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
- 200 kA interrupt rating complies with NEC section 110.9 for todays large capacity systems
- Fast acting fuse helps prevent equipment damage caused by short circuit events
- Rejection type fuse fits both standard and rejection style holders
- The class CC FNQ-R Limitron fuse meets the needs of control circuit transformer protection
- FNQ-R fuses can be sized according to NEC and UL requirements and still allow the high inrush currents, with significantly more time delay than the UL minimum value of 12 s at 200% for class CC fuses
- Nickel plated brass end caps
- 200 kA AC (RMS symmetrical)
- https://www.youtube.com/watch?v=YMvqUyoETXk
FNQ-R-10 Standards
CE Certified|CSA File No.53787-HRC-MISC|RoHS Compliant|UL 248-4 File No.E4273 Guide No. JDDZSKU #7601Part Number #FNQ-R-10UNSPSC39121606UPC00051712497091
