Part Number # FNQ-R-20
SKU # 7607
Image Disclaimers Message
Brand: Bussmann
FNQ-R-20
Bussmann FNQ-R-20 Time Delay Fuse
Part Number # FNQ-R-20
SKU # 7607
$584.90 / 10Each
Typical price:$859.70 / Each
Bussmann FNQ-R-20 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | FNQ-R-20 |
| SKU #: | 7607 |
| Amperage Rating: | 20, 20 A |
| Body Type: | Cylindrical |
| Class: | CC |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 20/200 kA, 200/20 |
| Rejection/Non-Rejection: | Rejection |
| Response Time: | 12, 12 s at 200% |
| Series: | FNQ-R |
| Terminal Type: | Ferrule |
| Country of origin: | MX |
| Material: | Melamine |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121606 |
| UPC: | 00051712497121 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$584.90 / 10Each
Typical price:$859.70 / Each
Quantity:
- Bussmann CC-Tron Time Delay Fuse, Series: FNQ-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 20 A, 600 V AC/300 V DC, 20/200 kA Interrupt, Class: CC, 12 s at 200% Response, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Melamine, 13/32 in Dia x 1-1/2 in L Body Size
FNQ-R-20 Application
Line Protection, Small Control Transformers, Industrial Control and Isolated/In-Line Fuse Holders Applications, Safety and Security SystemsFNQ-R-20 Item Features
- Time delay compatible with inrush characteristic of small control transformers
- Current limitation at class CC levels provides maximum component short circuit current rating protection
- 200 kA interrupt rating provides high ratings for control circuit locations
- Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
- Nickel plated brass end caps
- https://www.youtube.com/watch?v=YMvqUyoETXk
FNQ-R-20 Standards
CE Certified|CSA 1422-01|CSA File No. 53787-HRC-MISC|RoHS Compliant|UL 248-4|UL File No. E4273|UL Guide JDDZSKU #7607Part Number #FNQ-R-20UNSPSC39121606UPC00051712497121
