Bussmann FRN-R-150 Time Delay Fuse
Part Number # FRN-R-150
SKU # 2135287
Bussmann FRN-R-150 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | FRN-R-150 |
| SKU #: | 2135287 |
| Amperage Rating: | 150, 150 A |
| Body Type: | Blade |
| Interrupt Rating: | 20/200 |
| Response Time: | 10 |
| UNSPSC: | 39121606 |
| UPC: | 00051712101875 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann FRN-R-150 Time Delay Fuse
Brand: Bussmann
Part Number: FRN-R-150
Bussmann Fusetron Time Delay Fuse, Current Limiting, Series: FRN-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 150 A, 250 VAC/125 VDC, 20/200 kA Interrupt, Class: RK5, 10 s at 500% Response, Blade Terminal, Holder Mount, Blade Body Type, Dual Element, Fiberglass, 1.56 in Dia x 7.13 in L Body Size
Additional Description: BUSS-FRN-R-150 (N) FUSETRON DUAL-ELEMENT CLASS RK5 NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann Series Class RK5 fuse, FRN-R, time-delay, dual-element, current limiting fuse, 150 A, non-indicating fuse, interrupting rating of 200 kA at 250 Vac and 20 kA at 125 Vdc
FRN-R-150 Application
Combination Starters, Machinery Disconnects, Motor Control Centers and Power Panelboard Applications, Safety and Security SystemsFRN-R-150 Item Features
- Provides motor overload, ground fault and short circuit protection
- Helps protect motors against burnout from overloads and single phasing when sized properly
- Simplifies and improves blackout prevention (selective co-ordination ratios)
- Dual element fuses can be applied in circuits subject to temporary motor overloads and surge currents to provide both high performance short circuit and overload protection
- The overload element provides protection against low level over current of overloads and will hold on inrush current which is five times greater than the ampere rating of the fuse for a minimum of 10 s
- 200 kA at 250 VAC, 20 kA at 125 VDC interrupt rating
- https://www.youtube.com/watch?v=YMvqUyoETXk
FRN-R-150 Standards
CE Certified|CSA C22.2 No. 248.12|CSA File No. 53787/1422-02|UL 248-12|UL File No. E4273|UL Guide JDDZSKU #2135287Part Number #FRN-R-150UNSPSC39121606UPC00051712101875
