Part Number # JJN-500
SKU # 2403417
Image Disclaimers Message
JJN-500
Bussmann JJN-500 Limitron T-Tron Fuse
Part Number # JJN-500
SKU # 2403417
$357.51 / Each
Typical price:$727.01 / Each
Bussmann JJN-500 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | JJN-500 |
| SKU #: | 2403417 |
| Amperage Rating: | 500 A |
| Body Type: | Cartridge |
| Class: | T |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 200/20 kAIC |
| Rejection/Non-Rejection: | Non-Rejection |
| Series: | JJN |
| Terminal Type: | Bolted Blade End |
| Type: | Current Limiting Very Fast Acting |
| Material: | Melamine |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712627559 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$357.51 / Each
Typical price:$727.01 / Each
Quantity:
- Bussmann Limitron T-Tron Fuse, Current Limiting Very Fast Acting, Series: JJN, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 500 A, 300 V AC/160 V DC, 200/20 kAIC Interrupt, Class: T, Bolted Blade End Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine, 1.25 in Dia x 3.06 in L Body Size
JJN-500 Application
Industrial Facilities and Factories, Safety and Security Systems, Large Apartment Complexes, Multi-Family Meter Stacks, VFD Line Protection and Commercial ApplicationsJJN-500 Item Features
- Small footprint allows more efficient use of available space
- Series combination ratings with branch circuit breakers allows broad range of coverage, independent of breaker manufacturer
- Current limitation for non-inductive circuits provides class T current limiting response to maximum ground fault and short circuit conditions
- 200 kA interrupt rating complies with NEC section 110.9 for todays large capacity systems
- Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
- Fast acting fuse helps prevent equipment damage caused by short circuit events
- Small, space saving fuses provide a high degree of current limitation on short circuits for excellent component protection
- https://www.youtube.com/watch?v=YMvqUyoETXk
JJN-500 Standards
CE Certified|CSA C22.2 File No.53787|RoHS Compliant|UL 248-15 File No.E4273SKU #2403417Part Number #JJN-500UNSPSC39121626UPC00051712627559
