Part Number # JJS-2
SKU # 2344111
Image Disclaimers Message
JJS-2
Bussmann JJS-2 Fast Acting Fuse
Part Number # JJS-2
SKU # 2344111
$638.90 / 10Each
Typical price:$1299.10 / Each
Bussmann JJS-2 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | JJS-2 |
| SKU #: | 2344111 |
| Amperage Rating: | 2, 2 A |
| Body Type: | Cylindrical |
| Class: | T |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 200, 200 kA |
| Rejection/Non-Rejection: | Non-Rejection |
| Series: | JJS |
| Terminal Type: | Ferrule |
| Type: | Current Limiting, Fast Acting Current Limiting |
| Material: | Melamine |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712628143 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$638.90 / 10Each
Typical price:$1299.10 / Each
Quantity:
- Bussmann Limitron Fuse, Fast Acting Current Limiting, Series: JJS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 2 A, 600 V AC, 200 kA Interrupt, Class: T, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Single Element, Melamine, 0.56 in Dia x 1.5 in L Body Size
JJS-2 Application
Large Apartment Complexes, Multi-Family Meter Stacks, VFD Line Protection, Safety and Security SystemsJJS-2 Item Features
- Small footprint allows more efficient use of available space
- Series combination ratings with branch circuit breakers allows broad range of coverage, independent of breaker manufacturer
- Current limitation for non-inductive circuits provides class T current limiting response to maximum ground fault and short circuit conditions
- 200 kA interrupt rating complies with NEC Section 110.9 for todays large capacity systems
- Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
- Fast acting fuse helps prevent equipment damage caused by short circuit events
- Small, space saving fuses provide a high deg of current limitation on short circuits for excellent component protection
- https://www.youtube.com/watch?v=YMvqUyoETXk
JJS-2 Standards
CE Certified|CSA C22.2 File No.53787|NEC 110.9|RoHS Compliant|UL 248-15 File No. E4273SKU #2344111Part Number #JJS-2UNSPSC39121626UPC00051712628143
