Part Number # KLU-1000
SKU # 2239211
Image Disclaimers Message
KLU-1000
Bussmann KLU-1000 Time Delay Fuse
Part Number # KLU-1000
SKU # 2239211
$2195.07 / Each
Typical price:$4068.78 / Each
Bussmann KLU-1000 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | KLU-1000 |
| SKU #: | 2239211 |
| Amperage Rating: | 1000, 1000 A |
| Body Type: | Cartridge |
| Class: | L |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 200, 200 kAIC |
| Rejection/Non-Rejection: | Non-Rejection |
| Response Time: | 5, 5 s at 500% |
| Series: | KLU |
| Terminal Type: | Bolted Blade, Bolted Blade End |
| Type: | Current Limiting General Purpose, Current Limiting Time Delay |
| Country of origin: | MX |
| Material: | Fiberglass/Melamine |
| Mounting type: | Bolt-On, Bolted-On |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712135061 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$2195.07 / Each
Typical price:$4068.78 / Each
Quantity:
- Bussmann Limitron Fuse, Current Limiting Time Delay, Series: KLU, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 1000 A, 600 V, 200 kAIC Interrupt, Class: L, 5 s at 500% Response, Bolted Blade End Terminal, Bolted-On Mount, Cartridge Body, Dual Element, Fiberglass/Melamine, 2-1/2 in Dia x 10-3/4 in L Body Size
KLU-1000 Application
Industrial Facilities and Factories, Safety and Security Systems, Large Distribution Switchboards, Large Machinery Disconnects, Power Panelboards and General Purpose ApplicationsKLU-1000 Item Features
- Copper links result in a minimum 5 s time delay at 500% ampere rating
- Current limiting - provides component short circuit protection
- 200 kA interrupt rating complies with NEC section 110.9/230.65 in todays large capacity systems
- Selective coordination (blackout prevention)
- https://www.youtube.com/watch?v=YMvqUyoETXk
KLU-1000 Standards
CE Certified|CSA C22.2 File No.53787/248.1|NEC 110.9/230.65|RoHS Compliant|UL 248-10 File No.E4273 Guide JDDZSKU #2239211Part Number #KLU-1000UNSPSC39121626UPC00051712135061
