KLU-3000
Bussmann KLU-3000 Time Delay Fuse
Part Number # KLU-3000
SKU # 2252271
Bussmann KLU-3000 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | KLU-3000 |
| SKU #: | 2252271 |
| Amperage Rating: | 3000, 3000 A |
| Body Type: | Cartridge |
| Class: | L |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 200, 200 kAIC |
| Rejection/Non-Rejection: | Non-Rejection |
| Response Time: | 5, 5 s at 500% |
| Series: | KLU |
| Terminal Type: | Bolted Blade End, Knife Blade |
| Type: | Current Limiting, Current Limiting Time Delay |
| Country of origin: | MX |
| Material: | Fiberglass/Melamine |
| Mounting type: | Bolt-On, Bolted-On |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712497039 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann KLU-3000 Time Delay Fuse
Brand: Bussmann
Part Number: KLU-3000
Bussmann Limitron Fuse, Current Limiting Time Delay, Series: KLU, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 3000 A, 600 V, 200 kAIC Interrupt, Class: L, 5 s at 500% Response, Bolted Blade End Terminal, Bolted-On Mount, Cartridge Body, Single Element, Fiberglass/Melamine, 5 in Dia x 10-3/4 in L Body Size
Additional Description: BUSS-KLU-3000 LIMITRON TIME DELAY FUSE
Catalog Description: Eaton Bussmann Series Class L fuse, KLU, fast-acting, current limiting fuse, 3000 A, bladable fuse, interrupting rating of 200 kA, 600 Vac
KLU-3000 Application
Industrial Facilities and Factories, Safety and Security Systems, Large Distribution Switchboards, Large Machinery Disconnects and Power Panelboards ApplicationsKLU-3000 Item Features
- Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
- Fast acting fuse helps prevent equipment damage caused by short circuit events
- Copper links result in a minimum 5 s time delay at 500% ampere rating
- https://www.youtube.com/watch?v=YMvqUyoETXk
KLU-3000 Standards
CE Certified|CSA C22.2 File No.53787/248.10|NEC 110.9|RoHS Compliant|UL File No.E4273/248-10 Guide JDDZSKU #2252271Part Number #KLU-3000UNSPSC39121626UPC00051712497039
