Bussmann KTK-R-1/10
Part Number # KTK-R-1/10
SKU # 2451495
KTK-R-1/10
Bussmann KTK-R-1/10
Part Number # KTK-R-1/10
SKU # 2451495
Bussmann KTK-R-1/10 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | KTK-R-1/10 |
| SKU #: | 2451495 |
| Amperage Rating: | 0.1 A |
| Body Type: | Cartridge |
| Class: | CC |
| Interrupt Rating: | 200 kAIC |
| Rejection/Non-Rejection: | Rejection |
| Series: | KTK-R |
| Terminal Type: | Ferrule End |
| Type: | Current Limiting Fast Acting Low Voltage |
| Material: | Melamine Tube |
| Mounting type: | Holder |
| UNSPSC: | 39121606 |
| UPC: | 00051712420518 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann KTK-R-1/10
Brand: Bussmann
Part Number: KTK-R-1/10
Bussmann Limitron Fuse, Current Limiting Fast Acting Low Voltage, Series: KTK-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 0.1 A, 600 V AC, 200 kAIC Interrupt, Class: cc, Ferrule End Terminal, Holder Mount, Cartridge Body, Single Element, Melamine Tube, 13/32 in Dia x 1-1/2 in L Body Size
Additional Description: BUSS-KTK-R-1/10 CLASS CC FAST ACTING FUSE
Catalog Description: Eaton Bussmann Series Class CC fuse, KTK-R, fast-acting, dual-element current limiting fuse, 0.1 A, rejection style fuse, interrupting rating of 200kA at 600Vac
KTK-R-1/10 Application
Industrial Facilities and Factories, Safety and Security Systems, Specialized Circuits, Branch Circuits, Street Lighting, Isolated and In-Line Fuse Holders ApplicationsKTK-R-1/10 Item Features
- Current limitation at class CC levels provides maximum component short circuit current protection
- 200 kA interrupt rating provides high ratings at all circuit locations
- Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
- Nickel plated bronze end caps
- https://www.youtube.com/watch?v=YMvqUyoETXk
KTK-R-1/10 Standards
CE Certified|CSA C22.2 File No.53787/248.4|RoHS Compliant|UL 248-14 File No.E19180 Guide JDYXSKU #2451495Part Number #KTK-R-1/10UNSPSC39121606UPC00051712420518
Image provided may only be a representation of final product and may include optional equipment
