Part Number # KTS-R-80
SKU # 2275599
Image Disclaimers Message
KTS-R-80
Bussmann KTS-R-80 Fast Acting Fuse
Part Number # KTS-R-80
SKU # 2275599
$397.01 / Each
Typical price:$807.33 / Each
Bussmann KTS-R-80 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | KTS-R-80 |
| SKU #: | 2275599 |
| Amperage Rating: | 80, 80 A |
| Body Type: | Cartridge |
| Class: | RK1 |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 200, 200 kAIC |
| Rejection/Non-Rejection: | Rejection |
| Series: | KTS-R |
| Terminal Type: | Blade, Blade End |
| Type: | Current Limiting Fast Acting Low Voltage, Current Limiting Low Voltage |
| Material: | Melamine, Melamine Glass Tube |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712417143 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$397.01 / Each
Typical price:$807.33 / Each
Quantity:
- Bussmann Limitron Fuse, Current Limiting Fast Acting Low Voltage, Series: KTS-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 80 A, 600 V, 200 kAIC Interrupt, Class: RK1, Blade End Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine Glass Tube, 1 in Dia x 7.88 in L Body Size
KTS-R-80 Application
Industrial Facilities and Factories, Safety and Security Systems and Panelboard ApplicationsKTS-R-80 Item Features
- Current limitation for non-inductive circuits provides class RK1 current limiting response to maximum ground fault and short circuit conditions
- 200 kA interrupt rating provides high ratings at all circuit locations
- Economical solutions for high fault circuits
- 70/30 brass end cap
- Melamine tube with silver fuse element
- https://www.youtube.com/watch?v=YMvqUyoETXk
KTS-R-80 Standards
CE Certified|CSA C22.2 File No.53787/248.12|UL 248-12 File No.E4273 Guide JDDZSKU #2275599Part Number #KTS-R-80UNSPSC39121626UPC00051712417143
