Part Number # KTU-3000
SKU # 2290406
Image Disclaimers Message
KTU-3000
Bussmann KTU-3000 Fast Acting Fuse
Part Number # KTU-3000
SKU # 2290406
$6123.36 / Each
Typical price:$12451.85 / Each
Bussmann KTU-3000 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | KTU-3000 |
| SKU #: | 2290406 |
| Amperage Rating: | 3000 A |
| Body Type: | Cartridge |
| Class: | L |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 200 kAIC |
| Rejection/Non-Rejection: | Non-Rejection |
| Series: | KTU |
| Terminal Type: | Bolted Blade End |
| Type: | Current Limiting Fast Acting |
| Country of origin: | MX |
| Material: | Melamine Glass Tube |
| Mounting type: | Bolted-On |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712613309 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$6123.36 / Each
Typical price:$12451.85 / Each
Quantity:
- Bussmann Limitron Fuse, Current Limiting Fast Acting, Series: KTU, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 3000 A, 600 V, 200 kAIC Interrupt, Class: L, Bolted Blade End Terminal, Bolted-On Mount, Cartridge Body, Single Element, Melamine Glass Tube, 5 in Dia x 10-3/4 in L Body Size
KTU-3000 Application
Industrial Facilities and Factories, Safety and Security Systems, Large Distribution Switchboards and Power Panelboards ApplicationsKTU-3000 Item Features
- Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
- Fast acting fuse helps prevent equipment damage caused by short circuit events
- O-ring seals maximize pressure build-up during current limiting action and ensure filter retention
- 99.9% pure silver links provide low watt loss with low operating temperature on normal current levels and minimizes total clearing it fault energy left through
- Ideal for critical industrial or commercial applications that have specific current limitation requirements
- Silver plated end bell
- https://www.youtube.com/watch?v=YMvqUyoETXk
KTU-3000 Standards
CE Certified|CSA C22.2 File No.53787/248.10|NEC 110.9|RoHS Compliant|UL File No.E4273/248-10 Guide JDDZSKU #2290406Part Number #KTU-3000UNSPSC39121626UPC00051712613309
