Bussmann LP-CC-1/2 Time Delay Fuse
Part Number # LP-CC-1/2
SKU # 8128
$519.90 / 10Each
Bussmann LP-CC-1/2 Key Features
Brand: Bussmann
Part Number # LP-CC-1/2
SKU #8128
Amperage Rating: 0.5, 0.5 A
Body Type: Cartridge
Class: CC
Indicating/Non-Indicating: Non-Indicating
Interrupt Rating: 20/200, 20/200 kA
Rejection/Non-Rejection: Rejection
Response Time: 12, 12 s at 200%
Series: LP-CC
Terminal Type: Ferrule
Type: Current Limiting
Voltage Rating: 600 VAC/300 VDC
Material: Melamine
Mounting type: Holder
Manufacturer Name: Eaton
UNSPSC: 39121606
UPC: 00051712180405
$519.90 / 10Each
Bussmann LP-CC-1/2 Time Delay Fuse
Brand: Bussmann
Part Number: LP-CC-1/2
Bussmann Low-Peak Time Delay Fuse, Current Limiting, Series: LP-CC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 0.5 A, 600 VAC/300 VDC, 20/200 kA Interrupt, Class: CC, 12 s at 200% Response, Ferrule Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 13/32 in Dia x 1-1/2 in L Body Size
Additional Description: BUSS-LP-CC-1/2 LOW PEAK CC TIME DELAY
Catalog Description: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 0.5 A, rejection style fuse, interrupting rating of 200kA at 600Vac and 20kA at 300Vdc.
LP-CC-1/2 Application
Branch Circuit Protection, Specialized Circuits, Industrial Control, Panels, Isolated and In-Line Fuse Holder, Safety and Security SystemsLP-CC-1/2 Item Features
- Time delay coupled with class CC current-limiting response provides close sizing on small motor and relay circuits and maximum component short circuit current rating protection
- 200 kA interrupt rating provides high ratings for control circuit locations
- Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
- Selective co-ordination ratio of 2:1 (within Low-Peak fuse family) prevents electrical shutdowns from extending beyond the failed circuit
- 200 kA at 600 VAC rms symmetrical, 20 kA at 300 VDC interrupt rating
- 120 s at 200% of ampere rating response time
- https://www.youtube.com/watch?v=YMvqUyoETXk
LP-CC-1/2 Standards
CE Certified|CSA 1422-02/File No. 53787|RoHS Compliant|UL 248-4|UL File No. E4273|UL Guide JDDZSKU #8128Part Number #LP-CC-1/2UNSPSC39121606UPC00051712180405
