LP-CC-12
Bussmann LP-CC-12 Time Delay Fuse
Part Number # LP-CC-12
SKU # 8130
$566.00 / 10Each
Typical price:$964.40 / Each
Bussmann LP-CC-12 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | LP-CC-12 |
| SKU #: | 8130 |
| Amperage Rating: | 12, 12 A |
| Body Type: | Cartridge |
| Class: | CC |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 20/200, 20/200 kA |
| Rejection/Non-Rejection: | Rejection |
| Response Time: | 12, 12 s at 200% |
| Series: | LP-CC |
| Terminal Type: | Ferrule |
| Type: | Current Limiting |
| Material: | Melamine |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121606 |
| UPC: | 00051712180252 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$566.00 / 10Each
Typical price:$964.40 / Each
Quantity:
- Bussmann Low-Peak Time Delay Fuse, Current Limiting, Series: LP-CC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 12 A, 600 V AC/150 V DC, 20/200 kA Interrupt, Class: CC, 12 s at 200% Response, Ferrule Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 13/32 in Dia x 1-1/2 in L Body Size
LP-CC-12 Application
Branch Circuit Protection, Specialized Circuits, Industrial Control, Panels, Isolated and In-Line Fuse Holder, Safety and Security SystemsLP-CC-12 Item Features
- Time delay coupled with class CC current-limiting response provides close sizing on small motor and relay circuits and maximum component short circuit current rating protection
- 200 kA interrupt rating provides high ratings for control circuit locations
- Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
- Selective co-ordination ratio of 2:1 (within Low-Peak fuse family) prevents electrical shutdowns from extending beyond the failed circuit
- 200 kA at 600 VAC rms symmetrical, 20 kA at 150 VDC interrupt rating
- 120 s at 200% of ampere rating response time
- https://www.youtube.com/watch?v=YMvqUyoETXk
LP-CC-12 Standards
CE Certified|CSA 1422-02/File No. 53787|RoHS Compliant|UL 248-4|UL File No. E4273|UL Guide JDDZSKU #8130Part Number #LP-CC-12UNSPSC39121606UPC00051712180252
