LPJ-175SP
Bussmann LPJ-175SP Time Delay Fuse
Part Number # LPJ-175SP
SKU # 8160
$426.30 / Each
Typical price:$726.33 / Each
Bussmann LPJ-175SP Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | LPJ-175SP |
| SKU #: | 8160 |
| Amperage Rating: | 175, 175 A |
| Body Type: | Cartridge |
| Class: | J |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 100/300 kA, 300/100 |
| Rejection/Non-Rejection: | Non-Rejection |
| Response Time: | 10, 10 s at 500% |
| Series: | LPJ |
| Terminal Type: | Bolted Blade, Knife Blade |
| Type: | Current Limiting |
| Material: | Melamine |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121626 |
| UPC: | 00051712523448 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$426.30 / Each
Typical price:$726.33 / Each
Quantity:
- Bussmann Low-Peak Time Delay Fuse, Current Limiting, Series: LPJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 175 A, 600 V AC/300 V DC, 100/300 kA Interrupt, Class: J, 10 s at 500% Response, Bolted Blade Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 1.63 in Dia x 5.75 in L Body Size
LPJ-175SP Application
Branch Circuit Breaker Panelboard Mains, Industrial Control, Machinery Disconnects and Power Panelboard Applications, Safety and Security SystemsLPJ-175SP Item Features
- Separate overload and short circuit elements provide time delay for sizing of high inrush loads linked with class J current limitation
- Selective co-ordination ratio of 2:1 (within Low-Peak fuse family) prevents electrical shutdowns from extending beyond the failed circuit
- Series combination ratings with branch circuit breakers allows broad range of coverage, independent of breaker manufacturer
- Proper sizing can provide "no damage" type 2 motor starter protection for NEMA and IEC motor controllers
- Space saving package for equipment down sizing
- Industrys only UL listed and CSA certified fuse with a 300 kea interrupt rating that allows for simple, worry free installation in virtually any application
- Fast short circuit protection and dual element, time delay performance provide ultimate protection
- Reduces existing fuse inventory by up to 33% when upgrading to Low-Peak fuses
- Consistent 2:1 ampacity ratios for all Low-Peak fuses make selective co-ordination easy
- Long time delay minimizes needless fuse openings due to temporary overloads and transient surges
- Current limitation protects downstream components against damaging thermal and magnetic effects of short circuit currents
- Dual element fuses have lower resistance than ordinary fuses, hence they run cooler
- They can often be sized for back up protection against motor burnout from overload or single phasing if other overload protective devices fail
- https://www.youtube.com/watch?v=YMvqUyoETXk
LPJ-175SP Standards
CE Certified|CSA C22.2 No. 248.8/1422-02/File No. 53787|RoHS Compliant|UL File No. E4273|UL File No. E56412|UL Guide JDDZ/JFHRSKU #8160Part Number #LPJ-175SPUNSPSC39121626UPC00051712523448
