LPJ-4-1/2SP
Bussmann LPJ-4-1/2SP Time Delay Fuse
Part Number # LPJ-4-1/2SP
SKU # 44284
Bussmann LPJ-4-1/2SP Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | LPJ-4-1/2SP |
| SKU #: | 44284 |
| Amperage Rating: | 4.5 A |
| Body Type: | Cylindrical |
| Class: | J |
| Interrupt Rating: | 300/100 kAIC |
| Rejection/Non-Rejection: | Non-Rejection |
| Response Time: | 10 s at 500% |
| Series: | LPJ |
| Terminal Type: | Ferrule End |
| Type: | Current Limiting Time Delay |
| Mounting type: | Holder |
| UNSPSC: | 39121626 |
| UPC: | 00051712522786 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann LPJ-4-1/2SP Time Delay Fuse
Brand: Bussmann
Part Number: LPJ-4-1/2SP
Bussmann Low-Peak Fuse, Current Limiting Time Delay, Series: LPJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 4.5 A, 600 V AC/300 V DC, 300/100 kAIC Interrupt, Class: J, 10 s at 500% Response, Ferrule End Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Melamine, 0.81 in Dia x 2.25 in L Body Size
Additional Description: BUSS-LPJ-4-1/2SP LOW-PEAK CLASS J T/D
Catalog Description: Eaton Bussmann Series Class J fuse, LPJ, time-delay, dual-element current limiting fuse, 4.5 A, non-idicating fuse, interrupting rating of 300 kA at 600 Vac and 100 kA at 300 Vdc
LPJ-4-1/2SP Application
Industrial Facilities and Factories, Safety and Security Systems, Branch Circuit Breaker, Panelboard Mains, Machinery Disconnects and Power Panelboard ApplicationsLPJ-4-1/2SP Item Features
- Industrys only UL listed and CSA certified fuse with a 300 kA interrupt rating that allows for simple, worry-free installation in virtually any application
- Fast short circuit protection and dual element, time delay performance provide ultimate protection
- Reduces existing fuse inventory by up to 33% when upgrading to Low-Peak fuses
- Consistent 2:1 ampacity ratios for all Low-Peak fuses make selective co-ordination easy
- Long time delay minimizes needless fuse openings due to temporary overloads and transient surges
- Current limitation protects downstream components against damaging thermal and magnetic effects of short circuit currents
- Dual element fuses have lower resistance than ordinary fuses so they run cooler
- Can often be sized for back up protection against motor burnout from overload or1 ph if other overload protective devices fail
- Proper sizing can provide "no damage" type 2 co-ordinated protection for NEMA and IEC motor controllers
- Space saving package for equipment downsizing
- 300 kA at 600 VAC, 100 kA at 300 VDC interrupt rating
- https://www.youtube.com/watch?v=YMvqUyoETXk
LPJ-4-1/2SP Standards
CE Certified|CSA C22.2 File No.53787/248.8|RoHS Compliant|UL File No.E4273 Guide JDDZSKU #44284Part Number #LPJ-4-1/2SPUNSPSC39121626UPC00051712522786
Image provided may only be a representation of final product and may include optional equipment
