Bussmann LPN-RK-35SP Time Delay Fuse
Part Number # LPN-RK-35SP
SKU # 2236738
$417.00 / 10Each
Bussmann LPN-RK-35SP Key Features
Brand: Bussmann
Part Number # LPN-RK-35SP
SKU #2236738
Amperage Rating: 35, 35 A
Body Type: Cartridge
Class: RK1
Indicating/Non-Indicating: Non-Indicating
Interrupt Rating: 100/300 kA, 300/100
Rejection/Non-Rejection: Rejection
Response Time: 10, 10 s at 500%
Series: LPN-RK
Terminal Type: Ferrule
Type: Current Limiting
Voltage Rating: 250 VAC/125 VDC, 250 VAC/VDC
Country of origin: MX
Material: Melamine
Mounting type: Holder
Manufacturer Name: Eaton
UNSPSC: 39121606
UPC: 00051712538374
$417.00 / 10Each
Bussmann LPN-RK-35SP Time Delay Fuse
Brand: Bussmann
Part Number: LPN-RK-35SP
Bussmann Low-Peak Time Delay Fuse, Current Limiting, Series: LPN-RK, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 35 A, 250 VAC/VDC, 100/300 kA Interrupt, Class: RK1, 10 s at 500% Response, Ferrule Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 0.81 in Dia x 3 in L Body Size
Additional Description: BUSS-LPN-RK-35SP LOW PEAK DUAL ELEMENT
Catalog Description: Eaton Bussmann Series Class RK1 fuse, LPN-RK, time-delay, dual-element, current limiting fuse, 35 A, non-indicating fuse, interrupting rating of 300 kA at 250 Vac and 100 kA at 125 Vdc
LPN-RK-35SP Application
Large Distribution Switchboards, Power Panelboards, Motor Control Centers and Machinery Disconnect Switches, Safety and Security SystemsLPN-RK-35SP Item Features
- Fast short circuit protection and dual element, time delay performance provide ultimate protection
- Insulated end caps reduces exposure to live parts and extends air gap to distance between blades of adjacent mounted fuses or to housing
- Current limitation protects downstream components against damaging thermal and magnetic effects of short circuit currents
- Reduces existing fuse inventory by up to 33% when upgrading to Low-Peak fuses
- Consistent 2:1 ampacity ratios for all Low-Peak fuses make selective co-ordination easy
- Time delay that permits 130% FLA sizing for back up motor protection
- Inventory consolidation of class RK1, RK5 and H fuses for reduced SKU investment and minimizing potential for misapplying fuse
- Separate overload and short circuit elements provide time delay for close sizing of high inrush loads linked with RK1 current limitation and selective co-ordination ratio of 2:1 (within Low-Peak fuse family) prevents widespread blackouts
- Protects against 1 ph motor damage
- Proper sizing can provide "no damage" type 2 motor starter protection for NEMA and IEC motor controllers
- https://www.youtube.com/watch?v=YMvqUyoETXk
LPN-RK-35SP Standards
CE Certified|CSA 1422-02|CSA C22.2|CSA File No. 248.12|CSA File No. 53787|UL File No. E4273|UL Guide JDDZSKU #2236738Part Number #LPN-RK-35SPUNSPSC39121606UPC00051712538374
