Brand: Bussmann
Bussmann LPS-RK-150SPI Time Delay Fuse
Part Number # LPS-RK-150SPI
SKU # 2252025
$407.11 / Each
Bussmann LPS-RK-150SPI Key Features
Brand: Bussmann
Part Number # LPS-RK-150SPI
SKU #2252025
Amperage Rating: 150, 150 A
Body Type: Cartridge
Class: RK1
Indicating/Non-Indicating: Indicating
Interrupt Rating: 300/100, 300/100 kAIC
Rejection/Non-Rejection: Rejection
Response Time: 10 s at 500%
Series: LPS-RK, LPS-RK-SP
Terminal Type: Blade End, Knife Blade
Type: Current Limiting Time Delay
Voltage Rating: 600 VAC/300 VDC
Country of origin: MX
Material: Melamine
Mounting type: Holder
Manufacturer Name: Eaton
UNSPSC: 39121606
UPC: 00051712626941
$407.11 / Each
Bussmann LPS-RK-150SPI Time Delay Fuse
Brand: Bussmann
Part Number: LPS-RK-150SPI
Bussmann Low-Peak Fuse, Current Limiting Time Delay, Series: LPS-RK, Indicating/Non-Indicating: Indicating, Rejection/Non-Rejection: Rejection, 150 A, 600 VAC/300 VDC, 300/100 kAIC Interrupt, Class: RK1, 10 s at 500% Response, Blade End Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 1.61 in Dia x 9.63 in L Body Size
Additional Description: BUSS-LPS-RK-150SPI INDICATING LPS-RK 150SP
Catalog Description: Eaton Bussmann Series Class RK1 fuse, LPS-RK, time-delay, dual-element, current limiting fuse, 150 A, indicating fuse, interrupting rating of 300 kA at 600 Vac
LPS-RK-150SPI Application
Industrial Facilities and Factories, Safety and Security Systems, Feeder and Branch Circuits, Motors, Transformers, Solenoids and General Purpose Circuits ApplicationsLPS-RK-150SPI Item Features
- Current limitation for maximum short circuit protection and reduced arc flash hazard
- Easy selective coordination with all Low-Peak fuses using simple 2:1 ampacity ratio
- No damage type 2 protection for IEC and NEMA starters when properly sized
- High inrush current motor protection
- Time delay permits 130% FLA sizing for back-up motor overload protection and 1 ph protection
- Low wattage loss power consumption
- Electrically isolated end caps for additional safety
- VAC interrupt rating that exceeds requirements for virtually all applications
- https://www.youtube.com/watch?v=YMvqUyoETXk
LPS-RK-150SPI Standards
CE Certified|CSA C22.2 File 53787/248.12|UL File No.E4273 Guide JDDZSKU #2252025Part Number #LPS-RK-150SPIUNSPSC39121606UPC00051712626941
