Bussmann LPS-RK-90SP Time Delay Fuse
Part Number # LPS-RK-90SP
SKU # 8236
$809.70 / 5Each
Bussmann LPS-RK-90SP Key Features
Brand: Bussmann
Part Number # LPS-RK-90SP
SKU #8236
Amperage Rating: 90, 90 A
Body Type: Cartridge
Class: RK1
Indicating/Non-Indicating: Non-Indicating
Interrupt Rating: 300/100, 300/100 kAIC
Rejection/Non-Rejection: Rejection
Response Time: 10 s at 500%
Series: LPS-RK, LPS-RK-SP
Terminal Type: Blade End, Knife Blade
Type: Current Limiting Time Delay
Voltage Rating: 600 VAC/300 VDC
Country of origin: MX
Material: Melamine
Mounting type: Holder
Manufacturer Name: Eaton
UNSPSC: 39121606
UPC: 00051712548441
$809.70 / 5Each
Bussmann LPS-RK-90SP Time Delay Fuse
Brand: Bussmann
Part Number: LPS-RK-90SP
Bussmann Low-Peak Fuse, Current Limiting Time Delay, Series: LPS-RK, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 90 A, 600 VAC/300 VDC, 300/100 kAIC Interrupt, Class: RK1, 10 s at 500% Response, Blade End Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 1.11 in Dia x 7.88 in L Body Size
Additional Description: BUSS-LPS-RK-90SP LOW-PEAK DUAL ELEMENT
Catalog Description: Eaton Bussmann Series Class RK1 fuse, LPS-RK, time-delay, dual-element, current limiting fuse, 90 A, non-indicating fuse, interrupting rating of 300 kA at 600 Vac and 100 kA at 300 Vdc
LPS-RK-90SP Application
Industrial Facilities and Factories, Safety and Security Systems, Feeder and Branch Circuits, Motors, Transformers, Solenoids and General Purpose Circuits ApplicationsLPS-RK-90SP Item Features
- Current limitation for maximum short circuit protection and reduced arc flash hazard
- Easy selective coordination with all Low-Peak fuses using simple 2:1 ampacity ratio
- No damage type 2 protection for IEC and NEMA starters when properly sized
- High inrush current motor protection
- Time delay permits 130% FLA sizing for back-up motor overload protection and 1 ph protection
- Low wattage loss power consumption
- Electrically isolated end caps for additional safety
- VAC interrupt rating that exceeds requirements for virtually all applications
- https://www.youtube.com/watch?v=YMvqUyoETXk
LPS-RK-90SP Standards
CE Certified|CSA C22.2 File No.53787/248.12|RoHS Compliant|UL File No.E4273 Guide JDDZSKU #8236Part Number #LPS-RK-90SPUNSPSC39121606UPC00051712548441
