Bussmann PCE-5-R PC-Tron Fast Acting Fuse
Part Number # PCE-5-R
SKU # 2244707
$23.45 / 5Each
Bussmann PCE-5-R Key Features
Brand: Bussmann
Part Number # PCE-5-R
SKU #2244707
Amperage Rating: 5, 5 A
Indicating/Non-Indicating: Non-Indicating
Interrupt Rating: 10/300 to 1, 10/300 to 1 kA
Response Time: 4 hr, 10 s
Series: PCE
Terminal Type: Radial Lead
Type: Subminiature
Voltage Rating: 125 VAC, 400 VDC, 125 VAC/400 VDC
Country of origin: US
Mounting type: Through Hole
Manufacturer Name: Eaton
UNSPSC: 39121609
UPC: 00051712503846
$23.45 / 5Each
Bussmann PCE-5-R PC-Tron Fast Acting Fuse
Bussmann PC-Tron Fast Acting Fuse, Subminiature, Series: PCE, Non-Indicating, 5 A, 125 VAC, 400 VDC, 10/300 to 1 kA Interrupt, 4 hr, 10 s Response, Radial Lead Terminal, Through Hole Mounting, 0.29 in H x 0.3 in W x 0.095 in D Body
Additional Description: BUSS-PCE-5-R (N) PC TRON - ROHS NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series fast-acting fuse, 125 Vac, 400 Vdc
PCE-5-R Application
High Voltage DC ApplicationsPCE-5-R Item Features
- Board washable
- Radial leaded, fast acting through hole fuse
- 10 kA at 125 VAC, 300 to 1000 A at 450 VDC interrupt rating
- 4 hr maximum at 100% of ampere rating, 10 s maximum at 200% of ampere rating response time
- https://www.youtube.com/watch?v=YMvqUyoETXk
PCE-5-R Standards
RoHS Compliant|CSA File No. 053787|RoHS 2002/95/EC|UL File No. E19180 Recognized|CSA 42731SKU #2244707Part Number #PCE-5-RUNSPSC39121609UPC00051712503846
