PV-15A10F
Bussmann PV-15A10F Photovoltaic Fuse Link
Part Number # PV-15A10F
SKU # 2304591
Bussmann PV-15A10F Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | PV-15A10F |
| SKU #: | 2304591 |
| Body Type: | Cylindrical |
| Class: | gPV |
| Interrupt Rating: | 50 kA |
| Rejection/Non-Rejection: | Non-Rejection |
| Response Time: | 1 to 3 ms |
| Series: | PV Series |
| Terminal Type: | Ferrule End |
| Material: | Ceramic |
| Mounting type: | Holder |
| UNSPSC: | 39121625 |
| UPC: | 00051712204040 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann PV-15A10F Photovoltaic Fuse Link
Brand: Bussmann
Part Number: PV-15A10F
Bussmann High Speed Photovoltaic Fuse, Series: PV Series, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 15 A, 1 kV DC, 50 kA Interrupt, Class: gPV, 1 to 3 ms Response, Ferrule End Terminal, Holder Mount, Cylindrical Body, Single Element, Ceramic, 10 mm Dia x 38 mm L Body Size
Additional Description: BUSS-PV-15A10F 15AMP 1000V DC SOLAR FERRULE 10 X 38MM
Catalog Description: Eaton Bussmann series photovoltaic fuses, 1000 Vdc, 15A, 50 kAIC, Non Indicating, IEC 60269-6 type A, Class gPV, Time constant: 1-3 ms, Ferrule end x ferrule end
PV-15A10F Application
Solar Panel Combiner Boxes, Inverters, PV Wire Harnesses, Renewable Energy Generation, Alternative Energy Generation, Solar Renewable Energy Generation and Storage Systems Renewable Energy ApplicationsPV-15A10F Item Features
- Meets UL and IEC photovoltaic standards for global acceptance
- Low wattage loss performance for energy efficiency
- Low temperature rise performance for more precise sizing
- https://www.youtube.com/watch?v=YMvqUyoETXk
PV-15A10F Standards
CCC Marked|CE Marking|CSA 1422-30|CSA Certified File No.53787|IEC 60269-6|RoHS Compliant|UL 2579/61010-1 File No.E185559/E335324 Guide JFGASKU #2304591Part Number #PV-15A10FUNSPSC39121625UPC00051712204040
Image provided may only be a representation of final product and may include optional equipment
