Part Number # SC-10
SKU # 2410709
SC-10
Bussmann SC-10 Fuse
Part Number # SC-10
SKU # 2410709
Bussmann SC-10 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | SC-10 |
| SKU #: | 2410709 |
| Amperage Rating: | 10 A |
| Class: | G |
| Interrupt Rating: | 100/10 kAIC |
| Response Time: | 12 s at 200% |
| Series: | SC Series |
| Terminal Type: | Ferrule End |
| Type: | Current Limiting Time Delay |
| UNSPSC: | 39121609 |
| UPC: | 00051712250108 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann SC-10 Fuse
Brand: Bussmann
Part Number: SC-10
Bussmann Fuse, Current Limiting Time Delay, Series: SC Series, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 10 A, 600 VAC/170 VDC, 100/10 kAIC Interrupt, Class: G, 12 s at 200% Response, Ferrule End Terminal, Holder Mount, Cartridge Body Type, Melamine, 0.41 in Dia x 1.31 in L Body Size
Additional Description: BUSS-SC-10 BUSS SC FUSE CLASS G CLASS G
Catalog Description: Eaton Bussmann Series Class G fuse, SC, fast-acting, current limiting fuse, 10 A, rejection style fuse, interrupting rating of 100 kA at 600 Vac and 10 kA at 170 Vdc
SC-10 Application
Industrial Facilities and Factories, Safety and Security Systems, Fusible Branch Panel Boards, HV Branch Circuit Protection and General Purpose ApplicationsSC-10 Item Features
- Most economical overcurrent protection solution compared to circuit breakers
- For use in various non-demanding, general purpose applications
- Compact branch circuit units with high interrupt rating and current limitation
- Size rejection by length helps prevent over fusing
- Fuses 7 A and above have a degree of overload time delay that permits them to pass temporary overloads
- 100 kA at 600 VAC, 10 kA at 170 VDC interrupt rating
- https://www.youtube.com/watch?v=YMvqUyoETXk
SC-10 Standards
RoHS CompliantSKU #2410709Part Number #SC-10UNSPSC39121609UPC00051712250108
