Part Number # SC-50
SKU # 8442
Image Disclaimers Message
SC-50
Bussmann SC-50 General Purpose Fuse
Part Number # SC-50
SKU # 8442
$424.60 / 10Each
Typical price:$863.40 / Each
Bussmann SC-50 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | SC-50 |
| SKU #: | 8442 |
| Amperage Rating: | 50, 50 A |
| Body Type: | Cartridge |
| Class: | G |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 10/100, 10/100 kA |
| Rejection/Non-Rejection: | Rejection |
| Response Time: | 12, 12 s |
| Series: | SC Series |
| Terminal Type: | Ferrule |
| Type: | Current Limiting Time Delay |
| Country of origin: | MX |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121609 |
| UPC: | 00051712250504 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$424.60 / 10Each
Typical price:$863.40 / Each
Quantity:
- Bussmann General Purpose Fuse, Current Limiting Time Delay, Series: SC Series, Non-Indicating, Rejection, 50 A, 480 V AC/300 V DC, 10/100 kA Interrupt, Class: G, 12 s Response, Ferrule Terminal, Holder Mounting, Cartridge Body, 0.41 in Dia x 2.25 in L Body
SC-50 Application
Fusible Branch Panelboards and HVAC Branch Circuit Protection ApplicationsSC-50 Item Features
- Most economical overcurrent protection solution compared to circuit breakers
- For use in various non-demanding, general purpose applications
- Compact branch circuit units with high interrupt rating and current limitation
- Size rejection by length helps prevent over fusing
- Fuses 7 A and above have a degree of overload time delay that permits them to pass temporary overloads
- 100 kA at 480 VAC, 10 kA at 300 VDC interrupt rating
- https://www.youtube.com/watch?v=YMvqUyoETXk
SC-50 Standards
UL 248-5, Guide No. JDDZ, File No. E4273|CSA C22.2 No. 248.5|Class 1422-01, File No. 53787|CE CertifiedSKU #8442Part Number #SC-50UNSPSC39121609UPC00051712250504
