941105
Cablofil 941105
Part Number # 941105
SKU # 2442243
$164.17 / Each
Typical price:$197.00 / Each
Cablofil 941105 Key Features
| Brand: | Cablofil |
|---|---|
| Part Number # : | 941105 |
| SKU #: | 2442243 |
| Finish: | Black Painted |
| Overall Height: | 2 in |
| Rung Spacing: | 3.94 in |
| Series: | CF54 |
| Wire Size: | 5.9 mm |
| Country of origin: | MX |
| Length: | 120 in |
| Material: | 1008 Carbon Steel |
| Width: | 12 in |
| Manufacturer Name: | Legrand |
| UNSPSC: | 39131704 |
| UPC: | 00800388009080 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$164.17 / Each
Typical price:$197.00 / Each
Quantity:
- Cablofil Wire Mesh Cable Tray, Series: CF54, 12 in Width, 120 in Length, 3.94 in Rung Spacing, 2.21 in Siderail Height, 2 in Overall Height, 1008 Carbon Steel, 5.9 mm Wire, Black Painted
941105 Application
Cable Management Applications941105 Item Features
- Special Safe-T-Edge - protects installers from sharp ends while it prevents cables from fraying
- Wire mesh is smooth and round - to resist dirt and dust build-up
- Standard 10 ft lengths - straight and easy to handle
- Large mesh size (2 in wide by 4 in long ) - allows cable installers to route cables in and out at any point without cutting the tray
- 1 in to 6 in high flange side of the tray - prevents cables from falling off
- Dimensions are nominal - other sizes available on request
- Available in the following finishes - Electro Zinc, Hot Dipped Galvanized, Stainless Steel 316L, Black Painted, and other Painted
- http://www.youtube.com/watch?v=f9WkhSB9vq4
941105 Standards
RoHS Compliant|UL Listed|cUL Listed|NEMA VE-1|CSA C22.2 No. 126|ECCN File No. EAR99SKU #2442243Part Number #941105UNSPSC39131704UPC00800388009080
Image provided may only be a representation of final product and may include optional equipment
