Part Number # CA30CAN25PA
SKU # 2328960
Image Disclaimers Message
Brand: Carlo Gavazzi
CA30CAN25PA
Carlo Gavazzi CA30CAN25PA SocAtt Coated Abrasive Quick-Change Disc
Part Number # CA30CAN25PA
SKU # 2328960
$530.85 / 5Each
Typical price:$610.00 / Each
Carlo Gavazzi CA30CAN25PA Key Features
| Brand: | Carlo Gavazzi |
|---|---|
| Part Number # : | CA30CAN25PA |
| SKU #: | 2328960 |
| Amperage Rating: | 200, 200 mA |
| Backing Material: | 3-Ply Cloth |
| Contact Configuration: | NC-NO, NC/NO, NO-NC |
| Enclosure Type: | IP67/IP68/IP69 |
| Frequency Response: | 50, 50 Hz |
| Response Time: | +/-10, +/-10 ms |
| Sensing Distance: | 0 to 25, 0 to 25 mm |
| Sensing Method: | Non-Flush |
| Series: | CA30CAN, SocAtt |
| Size: | 81 mm L |
| Temperature Rating (Degrees F): | -22 to 185, -22 to 185 deg F |
| Type: | All Purpose Quick-Change |
| Connection type: | Cable |
| Material: | Thermoplastic Polyester |
| Output type: | PNP |
| Manufacturer Name: | Carlo Gavazzi |
| UNSPSC: | 41111926 |
| UPC: | 05709870386539 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$530.85 / 5Each
Typical price:$610.00 / Each
Quantity:
- Carlo Gavazzi Capacitive Proximity Switch, Series: CA30CAN, Non-Flush Sensing Method, 0 to 25 mm Sensing Distance, <=5 % Accuracy, PNP Output, NO-NC Contact Configuration, 10 to 40 V DC, 200 mA, 50 Hz Frequency Response, Cable Connection, +/-10 ms Response, 81 mm L Size, IP67/IP68/IP69 Enclosure, -22 to 185 deg F, Thermoplastic Polyester
CA30CAN25PA Item Features
- 4th Generation TRIPLESHIELD
- Adjustable sensing distance: 2 to 20 mm flush or 4 to 30 mm non-flush
- Protection from short-circuit, transients and reverse polarity
- Dust and humidity compensation
- Dust or temperature alarm output
- LED indications for power supply, output and stability
- IP67, IP68, IP69K, Nema 1, 2, 4, 4X, 5, 6, 6P, 12
- M30 Dia housing
- 3 to 20% hysteresis
- 10% ripple
- 100 nF capacitive load
- 12 mA no load supply current
- 2.0 VDC at 200 mA DC voltage drop
- 0.5 mA minimum operational current
- 100 uA OFF state current
- 200 ms power ON delay
- LED, yellow target detected
- LED, green power and detection stability
- 1 kVAC (rms) rated insulation voltage
- 7.5 Nm tightening torque
CA30CAN25PA Standards
CE Certified|cULus Listed|ECOLABSKU #2328960Part Number #CA30CAN25PAUNSPSC41111926UPC05709870386539
