Part Number # RA2450-D06
SKU # 2198122
Image Disclaimers Message
RA2450-D06
Carlo Gavazzi RA2450-D06 Solid State Relay
Part Number # RA2450-D06
SKU # 2198122
$1398.20 / 20Each
Typical price:$1580.00 / Each
Carlo Gavazzi RA2450-D06 Key Features
| Brand: | Carlo Gavazzi |
|---|---|
| Part Number # : | RA2450-D06 |
| SKU #: | 2198122 |
| Amperage Rating: | 50, 50 A |
| Coil Voltage: | 230, 230 VAC |
| Contact Form: | 1NO 1 Form A SPST, SPST/NO |
| Dimensions: | 57.8 mm H x 44.5 mm W x 29 mm D |
| Frequency Rating: | 45 to 65, 45 to 65 Hz |
| Number of Poles: | 1 |
| Temperature Rating (Degrees F): | -20 to 70, -20 to 70 deg C |
| Terminal Type: | Screw |
| Type: | Industrial |
| Mounting type: | Panel |
| Manufacturer Name: | Carlo Gavazzi |
| UNSPSC: | 32131001 |
| UPC: | 05350035013984 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1398.20 / 20Each
Typical price:$1580.00 / Each
Quantity:
- Carlo Gavazzi Solid State Relay, Industrial, 50 A, 0.5 W, 45 to 65 Hz, 230 VAC Coil, 1NO 1 Form A SPST, 1 Pole, Panel Mount, Screw Terminal, -20 to 70 deg C, 57.8 mm H x 44.5 mm W x 29 mm D
RA2450-D06 Application
For resistive, inductive and capacitive loadsRA2450-D06 Item Features
- AC Solid State Relay
- Zero switching
- Direct copper bonding technology
- Up to 1200 Vp blocking voltage
- Up to 480 VAC rms rated operational voltage
- 3 to 32 VDC, 10 to 90 VAC/DC and 90 to 280 VAC/DC 3 input range
- 4000 VAC rms OPTO (input output) isolation
- The zero switching relay switches ON when the sine curve just crosses zero and switches OFF when the current crosses zero
- The zero switching relay with antiparallel thyristor output is the most widely used industrial SSR due to its multiple application possibilities
- 3 to 32 VDC control voltage
- 650 Vp blocking voltage
- 20 V zero voltage turn-on
- 3 VDC pick-up voltage, 1 VDC drop out voltage, 32 VDC reverse voltage, 1.5 kOhm Input impedance, 1/2 cycle Response time pick-up, 0.5 ms Control pulse width, 1/2 cycle response time drop out
- 250 mA rms minimum operational current, 125 Arms rep overload current t=1 s, 600 Ap Non-rep. surge current t=10 ms, 3 m Arms Off-state leakage current at rated voltage and frequency, 1800 A2s I2t for fusing t=10 ms, 1.6 Vrms On-state voltage drop at rated current, 500 V/us critical dV/dt commutating and critical dV/dt off-state
- -40 to 100 deg C Storage temperature
- Noryl GFN 1 housing material, black color
RA2450-D06 Standards
UL Listed|CSA Certified|CE Marked|RoHS Compliant|PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.govSKU #2198122Part Number #RA2450-D06UNSPSC32131001UPC05350035013984
