Carlo Gavazzi RGC1A60A62KGU Solid State Relay
Part Number # RGC1A60A62KGU
SKU # 2268522
RGC1A60A62KGU
Carlo Gavazzi RGC1A60A62KGU Solid State Relay
Part Number # RGC1A60A62KGU
SKU # 2268522
Carlo Gavazzi RGC1A60A62KGU Key Features
| Brand: | Carlo Gavazzi |
|---|---|
| Part Number # : | RGC1A60A62KGU |
| SKU #: | 2268522 |
| Coil Voltage: | 600 V |
| Dimensions: | 2.76 in W x 5.35 in D x 4.33 in H |
| Series: | RGC |
| Manufacturer Name: | Carlo Gavazzi |
| UNSPSC: | 32131001 |
| UPC: | 05350035425480 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Carlo Gavazzi RGC1A60A62KGU Solid State Relay
Brand: Carlo Gavazzi
Part Number: RGC1A60A62KGU
Carlo Gavazzi Solid State Relay, Series: RGC, 65 A, 45 to 65 Hz Frequency, 600 V Coil, 1 Pole, DIN Rail/Panel Mounting, Box/Screw Terminal, IP20 Enclosure, -40 to 176 deg F, 2.76 in W x 5.35 in D x 4.33 in H Dimensions
Additional Description: CAGA-RGC1A60A62KGU 1P-SSC-AC IN-ZC 600V 65A 1200VP-U-SRW IN 1200V
Catalog Description: 1-pole DIN-rail mount SSR, U-layout, Zero-cross switching, Operating voltage (Ue): 42 - 660 Vac (1200 Vp), Rated current (Ie): 65 Aac, Control voltage (Uc): 20 - 275 Vac / 24 - 190 Vdc, Built-in overvoltage protection, High I2t
RGC1A60A62KGU Application
Plastic Injection Machines, Extrusion Machines, Blow Molding Machines, Thermoformers, Dryers, Electrical Ovens, Fryers, Shrink Tunnels, Air Handling Units, Sterilization Equipment, Climatic Chambers, Ovens and Furnaces and Ambient Heating ApplicationsRGC1A60A62KGU Item Features
- Ratings up to 660 VAC, 85 A at TA 40 deg C
- Up to 18000 A2s for I2t for protection coordination with MCBs
- 100 kA short circuit current rating according to UL 508
- Conformance to railway standards
- Zero cross switching
- 42 to 660 VAC, 1200 Vp rated voltage
- 20 to 275 VAC/24 to 190 VDC control voltage
- Screw connection for control terminals
- Box clamp connection for power terminals
- SSR configuration
RGC1A60A62KGU Standards
CSA C22.2 No. 14 File No. E172877/NMFT7|CE Certified|cUL Listed|cULus Listed|EAC Certified|EN/IEC 60947-4-2|EN/IEC 60947-4-3|GL Approved|UL 508 File No. E172877/NMFT|VDE 0660-109SKU #2268522Part Number #RGC1A60A62KGUUNSPSC32131001UPC05350035425480
Image provided may only be a representation of final product and may include optional equipment
