Brand: Carlo Gavazzi
RZ3A60A55
Carlo Gavazzi RZ3A60A55 Solid State Relay
Part Number # RZ3A60A55
SKU # 972436
$1309.05 / 5Each
Typical price:$1505.00 / Each
Carlo Gavazzi RZ3A60A55 Key Features
| Brand: | Carlo Gavazzi |
|---|---|
| Part Number # : | RZ3A60A55 |
| SKU #: | 972436 |
| Amperage Rating: | 3 x 55, 3 x 55 A |
| Coil Voltage: | 600, 600 VAC |
| Contact Form: | 3 Form A 3PST, 3PST/NO, NO/3PST |
| Dimensions: | 103 mm H x 73.5 mm W x 41 mm D |
| Display Type: | LED |
| Enclosure Type: | IP10 |
| Number of Pins: | 8 |
| Number of Poles: | 3 |
| Temperature Rating (Degrees F): | -30 to 80, -30 to 80 deg C |
| Terminal Type: | Screw |
| Type: | 3-Phase |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Carlo Gavazzi |
| UNSPSC: | 32131001 |
| UPC: | 05350035404126 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1309.05 / 5Each
Typical price:$1505.00 / Each
Quantity:
- Carlo Gavazzi Solid State Relay, 3-Phase, 3 x 55 A, 600 VAC Coil, 3 Form A 3PST Contact Form, 8 Pins, 3 Pole, DIN Rail Mounting, Screw Terminal, LED Display, IP10 Enclosure, -30 to 80 deg C, 103 mm H x 73.5 mm W x 41 mm D Dimensions
RZ3A60A55 Application
For heavy industrial applicationsRZ3A60A55 Item Features
- Zero switching
- Integral snubber network
- Built-in varistor
- Over-temperature protection option with alarm output
- LED indication of control input and over-temperature alarm status
- 24 - 275 VAC/24 - 50 VDC control voltage
- 42-660 VAC operational voltage range, 1600 Vp blocking voltage, III overvoltage category, 3 deg pollution
- 18 VAC/20 VDC pickup voltage, 9 VAC/DC dropout voltage, 15 mA Input current, 20 ms at 50 Hz pickup response time, 30 ms at 50 Hz dropout response time
- 250 mA rms minimum operational current, < 125 Arms rep overload current t=1 s, 600 Ap Non-rep. surge current t = 10 ms, < 3m Arms Off-state leakage current, 1800 A2s I2t for fusing t = 10 ms, 1.6 Vrms On-state voltage drop, 500 V/us critical dV/dt off-state
- Noryl material
- -40 to 100 deg C storage temperature
RZ3A60A55 Standards
UR|cUR Listed|CSA Certified|CE MarkedSKU #972436Part Number #RZ3A60A55UNSPSC32131001UPC05350035404126
