Part Number # AFU154
SKU # 2248770
AFU154
Crouse Hinds AFU154 Conveyor Belt Control Switch
Part Number # AFU154
SKU # 2248770
Crouse Hinds AFU154 Key Features
| Brand: | Crouse Hinds |
|---|---|
| Part Number # : | AFU154 |
| SKU #: | 2248770 |
| Action: | Momentary |
| Actuator: | Pull Ring Plunger |
| Contact Configuration: | 1NC |
| Dimensions: | 6-7/8 in W x 9-1/8 in H, 9-1/8 in H x 6-7/8 in W |
| Enclosure: | NEMA 3 |
| Mounting: | Wall |
| Series: | AFU, AFU Series |
| Type: | Explosionproof Heavy Duty Mine Signal Replacement |
| Country of origin: | US |
| Material: | Feraloy Iron Alloy, Feraloy® Iron Alloy |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39122205 |
| UPC: | 00782274026503 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Crouse Hinds AFU154 Conveyor Belt Control Switch
Brand: Crouse Hinds
Part Number: AFU154
EATON Crouse-Hinds Conveyor Belt Control Switch, Explosionproof Heavy Duty Mine Signal Replacement, Series: AFU Series, 600 VAC, 1NC Contact Configuration, Momentary Action, Pull Ring Plunger Actuator, NEMA 3 Enclosure, Wall Mounting, Feraloy Iron Alloy, 6-7/8 in W x 9-1/8 in H Dimensions
Additional Description: CRHD-AFU154 AFU-CS(JOY)-AF-AFB-SWITCHES REPLACEMENT
Catalog Description: Eaton Crouse-Hinds series AFU mine signal switch, Two normally open/two normally closed, Feraloy iron alloy, 25 lb total operating force, 600 Vac, 15 lb without switch
AFU154 Application
For signaling circuits or remote control of magnetic motor starters and non-hazardous areas, industrial facilities, factories facility, power distribution and control and wet location applicationsAFU154 Item Features
- Sturdy raintight enclosure with heavy mounting lugs
- Wires enter enclosure through clearance holes in the underside
- Switches are actuated by a spring loaded plunger which returns to the normal position when the operating force is removed
- Units are furnished with heavy duty motor control pushbuttons
- Used in non-hazardous areas of mines or process industry facilities where a rugged enclosure is needed for protection from falling ore and other material or dripping water
- Mounted on walls or in shaft ways and actuated by pulling line or cable attached to the loop at the bottom
- Steel plunger
- Bronze loop
- Electro galvanized with aluminum acrylic painted
- 15 lb maximum weight of unsupported line or cable without actuating switch
- 25 lb total operating force
SKU #2248770Part Number #AFU154UNSPSC39122205UPC00782274026503
Image provided may only be a representation of final product and may include optional equipment
