Brand: Crouse Hinds
EFD2419
Crouse Hinds EFD2419 Circuit Breaker
Part Number # EFD2419
SKU # 2304403
$1014.50 / Each
Typical price:$1339.14 / Each
Crouse Hinds EFD2419 Key Features
| Brand: | Crouse Hinds |
|---|---|
| Part Number # : | EFD2419 |
| SKU #: | 2304403 |
| Actuator Type: | Handle |
| Amperage Rating: | 20/30, 20/30 A |
| Dimensions: | 3-1/2 in W x 4-7/8 in D x 6-3/32 in H, 6-3/32 in H x 3-1/2 in W x 4-7/8 in D |
| Enclosure Type: | NEMA 3/12/7B/7C/7D/9E/9F/9G, NEMA 3/7B/7C/7D/9E/9F/9G/12 |
| Finish: | Aluminum Acrylic Painted/Electro-Galvanized, Electro-Galvanized/Aluminum Acrylic Painted |
| Frame: | QOU |
| Number of Poles: | 2, 3 |
| Series: | EFD |
| Trip Type: | Thermal Magnetic |
| Type: | 1-Gang Dead End, 1-Gang Dead End Explosionproof |
| Connection type: | Bolted/Ground, Bolted/Ground Joint |
| Country of origin: | BR |
| Material: | Feraloy Iron Alloy, Feraloy® Iron Alloy |
| Mounting type: | Flush/Wall |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121521 |
| UPC: | 00782274267401 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1014.50 / Each
Typical price:$1339.14 / Each
Quantity:
- Crouse-Hinds Circuit Breaker, 1-Gang Dead End Explosionproof, Series: EFD, 240/600 VAC, 20/30 A, 1 hp, 2 hp, 3 hp Power, QOU Frame, Thermal Magnetic Trip, 3 Pole, Handle Actuator, Bolted/Ground Joint Connection, NEMA 3/7B/7C/7D/9E/9F/9G/12 Enclosure, Flush/Wall Mounting, 3-1/2 in W x 4-7/8 in D x 6-3/32 in H Dimensions, Feraloy Iron Alloy, Aluminum Acrylic Painted/Electro-Galvanized
EFD2419 Application
Industrial Facilities, Factories, Power Distribution and Control, Motors, Flammable Vapors, Gases or Highly Combustible Dusts, Industrial, Chemical and Petrochemical Plant ApplicationsEFD2419 Item Features
- Accurately ground flange on both body and cover for flametight joint
- Switch can be padlocked in either on or off positions
- For manual starting of small AC or DC motors
- In locations made hazardous due to the presence of flammable vapors, gases or highly combustible dusts
- For installation at petroleum refineries, chemical and petrochemical plants and other process industry facilities where similar hazards exist
- Dust-ignitionproof and raintight
- 1 in hub
- 1 hp at 115 VAC, 2 hp at 230 VAC, 3 hp at 460 to 575 vac
EFD2419 Standards
UL 698|UL 1203|CSA C22.2 No. 30|Class I, Division 1/2, Group B/C/D, Class II, Division 1/2, Group E/F/G, Class IIISKU #2304403Part Number #EFD2419UNSPSC39121521UPC00782274267401
