EYSR3
Crouse Hinds EYSR3 Retrofit Sealing Fitting
Part Number # EYSR3
SKU # 2310936
$1614.94 / 2Each
Typical price:$2131.72 / Each
Crouse Hinds EYSR3 Key Features
| Brand: | Crouse Hinds |
|---|---|
| Part Number # : | EYSR3 |
| SKU #: | 2310936 |
| Dimensions: | 3-1/8 in H x 4-3/8 in W x 3-1/8 in D, 4-3/8 in W x 3-1/8 in D x 3-1/8 in H |
| Finish: | Aluminum Acrylic Painted/Electro-Galvanized, Electro-Galvanized |
| Series: | EYSR |
| Size: | 1 in, 1 in NPT |
| Suitable For Use With: | Vertical/Horizontal Positions Rigid Conduit System |
| Type: | Dust-Ignitionproof Explosionproof |
| Country of origin: | US |
| Material: | Feraloy Iron Alloy, Feraloy® Iron Alloy |
| Mounting type: | Surface |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121311 |
| UPC: | 00782274793375 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1614.94 / 2Each
Typical price:$2131.72 / Each
Quantity:
Crouse Hinds EYSR3 Retrofit Sealing Fitting
Brand: Crouse Hinds
Part Number: EYSR3
EATON Crouse-Hinds Condulet Retrofit Sealing Fitting, Dust-Ignitionproof Explosionproof, Series: EYSR, 1 in, For Use With: Vertical/Horizontal Positions Rigid Conduit System, Surface Mount, Feraloy Iron Alloy, Aluminum Acrylic Painted/Electro-Galvanized, 4-3/8 in W x 3-1/8 in D x 3-1/8 in H
Additional Description: CRHD-EYSR3 1 NPT DIV 2 CST IRON RETROFIT SEAL FTG 1/8 X 3 1/8 1/8 X 3
Catalog Description: Eaton Crouse-Hinds series EYSR retrofit sealing fitting, Feraloy iron alloy, 1"
EYSR3 Application
Industrial Facilities, Factories, Indoor and Outdoor ApplicationsEYSR3 Item Features
- Seal may be installed in the existing conduit RUN without disassembly of the conduit system, saving time and labor
- Overall length and spacing requirements do not exceed those of standard EYS seals, permits close nesting of seals
- Pipe plugs permit the installation of a standard ECD15 drain fitting (order separately) for use in vertical conduit runs to drain any water that might accumulate in the conduit system
- Steel set screws provide grounding continuity
- To restrict the passage of gases, vapors or flames from one portion of the electrical system to another
- To limit explosions to the sealed OFF enclosure
- To limit pre-compression or pressure piling in the conduit system
- To prevent accumulation of water in the conduit when installed with a drain
- Steel pipe plugs, bolts and set screws
- Neoprene gasket
EYSR3 Standards
CSA C22.2|Class I, Div 1, 2, Groups B, C, D Class II, Div 1, Groups E, F, G Class II, Div 2, Groups F, G Class III|UL 1203|UL 886SKU #2310936Part Number #EYSR3UNSPSC39121311UPC00782274793375
