Part Number # 1SNA113003R1000
SKU # 1711204
Image Disclaimers Message
1SNA113003R1000
ENTRELEC 1SNA113003R1000 The SCM circuit separator avoids the derating of terminal blocks when cut jumper bars are used
Part Number # 1SNA113003R1000
SKU # 1711204
ENTRELEC 1SNA113003R1000 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNA113003R1000 |
| SKU #: | 1711204 |
| Block Type: | Screw Clamp |
| Dimensions: | 21 mm H x 1.5 mm W x 22 mm L |
| Series: | SNA |
| Suitable For Use With: | Terminal Blocks and Strips |
| Type: | SCM6 |
| Color: | Gray, Grey |
| Material: | Polyamide |
| UNSPSC: | 39121425 |
| UPC: | 00662019954905 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ENTRELEC 1SNA113003R1000 The SCM circuit separator avoids the derating of terminal blocks when cut jumper bars are used
Brand: ENTRELEC
Part Number: 1SNA113003R1000
TE, 1SNA113003R1000, Circuit Separator, SCM6, Series: SNA, Screw Clamp Block, For Use With: Terminal Blocks and strips, Polyamide, Grey, 21 mm H x 1.5 mm W x 22 mm L Dimensions
Additional Description: TEC -1SNA113003R1000 SCM6 Circuit Separators Grey 011300310
Catalog Description: - The SCM circuit separator avoids the derating of terminal blocks when cut jumper bars are used, - Without spacing loss, - Extends 8 mm 0.315 in on top.
1SNA113003R1000 Specifications
- Does not increase the thickness of the blocks, but extends 0.315 in on top
- The SCM separator snaps onto the top of the open terminal blocks, once the terminal board is assembled
1SNA113003R1000 Item Features
- Screw clamp, stud technologies
- Available functions are feed-through, ground, disconnect, fuse, single to triple deck, test & measurement
- Power stud range available with stud-stud or stud-screw clamp technologies
- Ease the identification of functions inside cabinet thanks to large range of coloured variants
- The SNA connection technologies eliminate the need for retightening campaigns thanks dedicated anti-release system
- Avoid mounting and wiring errors thanks to asymmetrical design
- Allow installation flexibility with extra mounting options such as TS32 rail,panel or plate
- 50% faster assembly time thanks to the locking pin, 10 pre-assembled blocks plugged-in on rail at a time
- Elimination of faulty manouvers thanks to screw type jumper bars
SKU #1711204Part Number #1SNA113003R1000UNSPSC39121425UPC00662019954905
