Part Number # 1SNA115479R2300
SKU # 2186044
Image Disclaimers Message
Brand: ENTRELEC
1SNA115479R2300
ENTRELEC 1SNA115479R2300 Ease one potential distribution on 4 independent screw clamps
Part Number # 1SNA115479R2300
SKU # 2186044
$226.00 / 50Each
Typical price:$290.85 / Each
ENTRELEC 1SNA115479R2300 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNA115479R2300 |
| SKU #: | 2186044 |
| Amperage Rating: | 32, 32 A |
| Dimensions: | 2.5 in L x 0.0238 in W x 2.09 in H, 63.5 mm H x 6 mm W x 40.5 mm L |
| Number of Poles: | 1, 4 |
| Series: | SNA |
| Spacing: | 6, 6 mm |
| Temperature Rating (Degrees F): | -55 to 110, -55 to 110 deg C |
| Terminal Size: | M4/6.4A |
| Terminal Type: | Feed-Through, Screw |
| Torque Rating: | 0.5 N-m, 0.5 to 0.8, 0.5 to 0.8 N-m |
| Type: | M4/6.4A, Multi-Clamp |
| Wire Size: | 10, 10 AWG |
| Color: | Gray |
| Connection type: | Screw Clamp |
| Country of origin: | FR |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | ABB, TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00662019957050 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$226.00 / 50Each
Typical price:$290.85 / Each
Quantity:
- ABB Terminal Block, Multi-Clamp, Series: SNA, 800 VAC, 32 A, 1 Pole, 10 AWG Wire, 9.5 mm Wire Strip Length, Feed-Through Terminal, M4/6.4A Terminal, 6 mm Spacing, 0.5 to 0.8 N-m, DIN Rail Mount, Screw Clamp, -55 to 110 deg C, Polyamide, Gray, 2.5 in L x 0.0238 in W x 2.09 in H
1SNA115479R2300 Application
For energy, explosive atmospheres, maritime, material handling and traction industries, control panels and standard distribution applications1SNA115479R2300 Item Features
- Self-locking clamp design prevents screw loosening
- Funneled side entry for up to two ferruled or non - ferruled solid or stranded wires
- High quality steel offers a very high over - torque resistance
- 600 VAC main circuit voltage
- Clamp is protected from harsh environments by a zinc bichromate surface treatment
- Use with applications ranging from standard distribution and control panels
- Compensates for the flattening of copper under contact pressure
- Mounting on DIN rail G32 (32 x 15 mm mounting rail) according to IEC 60715 - TH35-7.5 (35 x 7.5 mm mounting rail) according to IEC 60715 - TH35-15 (35 x 15 mm mounting rail) according to IEC 60715
1SNA115479R2300 Standards
RoHS Compliant|EAC Certified|CE Certified|UL94 V-0 Flammability RatingSKU #2186044Part Number #1SNA115479R2300UNSPSC39121410UPC00662019957050
