Part Number # 1SNA115604R2100
SKU # 351439
1SNA115604R2100
ENTRELEC 1SNA115604R2100 Protect your circuits with 5x20 and 5x25 fuse terminal blocks (fuse not supplied with terminal blocks)
Part Number # 1SNA115604R2100
SKU # 351439
ENTRELEC 1SNA115604R2100 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNA115604R2100 |
| SKU #: | 351439 |
| Amperage Rating: | 6.3, 6.3 A |
| Dimensions: | 8 mm W x 59 mm D x 85.7 mm H, 85.7 mm H x 8 mm W x 59 mm D |
| Number of Poles: | 4 |
| Series: | SNA |
| Spacing: | 8, 8 mm |
| Temperature Rating (Degrees F): | -55 to 110, -55 to 110 deg C |
| Terminal Type: | Screw Clamp |
| Torque Rating: | 0.5 to 0.8 N-m |
| Type: | Double Deck, Double Deck Heavy Duty, Fused |
| Wire Size: | 12, 12 AWG |
| Connection type: | Screw Clamp |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121629 |
| UPC: | 00662019957401 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ENTRELEC 1SNA115604R2100 Protect your circuits with 5x20 and 5x25 fuse terminal blocks (fuse not supplied with terminal blocks)
Brand: ENTRELEC
Part Number: 1SNA115604R2100
ABB Fused Terminal Block, Double Deck, Series: SNA, 630 VAC, 6.3 A, 12 AWG Wire, 9.5 mm Wire Strip Length, Screw Clamp Terminal, 8 mm Spacing, 0.5 to 0.8 N-m Torque, DIN Rail Mounting, Screw Clamp Connection, -55 to 110 deg C, Polyamide, Gray, 8 mm W x 59 mm D x 85.7 mm H Dimensions
Additional Description: TEC -1SNA115604R2100 M4/8.D2.SF Screw Clamp Terminal Blocks - For 5 x 20 and 5 x 25 fuses - Grey 011560421
Catalog Description: - Protect your circuits with 5x20 and 5x25 fuse terminal blocks (fuse not supplied with terminal blocks), - Save space with double deck terminal blocks: 2 independent circuits 1 fuse on upper deck + 1 feed-through.
1SNA115604R2100 Item Features
- Protect your circuits with 5x20 and 5x25 fuse terminal blocks (fuse not supplied with terminal blocks)
- Save space with double deck terminal blocks 2-independent circuits 1 fuse on upper deck, 1 feed through
1SNA115604R2100 Standards
UL Listed|UL Recognized|CE Certified|CSA Certified|IEC Certified|UL 94 V-0 Flammability Rating|RoHS CompliantSKU #351439Part Number #1SNA115604R2100UNSPSC39121629UPC00662019957401
Image provided may only be a representation of final product and may include optional equipment
