1SNA165830R2100
ENTRELEC 1SNA165830R2100 Screwless rail contact
Part Number # 1SNA165830R2100
SKU # 2140341
ENTRELEC 1SNA165830R2100 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNA165830R2100 |
| SKU #: | 2140341 |
| Amperage Rating: | 720 A |
| Dimensions: | 49.7 mm H x 8 mm W x 41 mm D, 49.7 mm H x 8 mm W x 41 mm L |
| Number of Poles: | 2 |
| Series: | SNA |
| Spacing: | 0.314 in, 8, 8 mm |
| Temperature Rating (Degrees F): | -55 to 110, -55 to 110 deg C |
| Terminal Type: | Ground, Screw Clamp |
| Torque Rating: | 0.8 N-m, 1, 1 N-m |
| Type: | D6/8.P |
| Wire Size: | 8 AWG |
| Color: | Green/ Yellow, Green/Yellow |
| Connection type: | Screw, Screw Clamp |
| Country of origin: | FR |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00662019960463 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ENTRELEC 1SNA165830R2100 Screwless rail contact
Brand: ENTRELEC
Part Number: 1SNA165830R2100
TE, 1SNA165830R2100, Terminal Blocks, D6/8.P, Series: SNA, 3500 V, 720 A, 6 Pole, 8 AWG Wire, 12 mm Wire Strip Length, Clamp Terminal, 8 mm Spacing, 0.8 N-m Torque, DIN Rail Mounting, Screw Connection, -55 to 110?| deg C, Polyamide, Green/ Yellow, 49.7 mm H x 8 mm W x 41 mm L Dimensions
Additional Description: TEC -1SNA165830R2100 D6/8.P Screw Clamp Terminal Blocks - Ground - Green-Yellow 016583021
Catalog Description: - Screwless rail contact, - Reliable electrical and mechanical contact with the rail.
1SNA165830R2100 Application
For Signal1SNA165830R2100 Item Features
- Screw clamp, stud technologies
- Available functions are feed-through, ground, disconnect, fuse, single to triple deck, test & measurement
- Power stud range available with stud-stud or stud-screw clamp technologies
- Ease the identification of functions inside cabinet thanks to large range of coloured variants
- The SNA connection technologies eliminate the need for retightening campaigns thanks dedicated anti-release system
- Avoid mounting and wiring errors thanks to asymmetrical design
- Allow installation flexibility with extra mounting options such as TS32 rail,panel or plate
- 50% faster assembly time thanks to the locking pin, 10 pre-assembled blocks plugged-in on rail at a time
- Elimination of faulty manouvers thanks to screw type jumper bars
1SNA165830R2100 Standards
UL 94V-0|EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|China RoHS 2 Directive MIIT Order No 32, 2016|EU REACH Regulation (EC) No. 1907/2006|PROP65SKU #2140341Part Number #1SNA165830R2100UNSPSC39121410UPC00662019960463
