ENTRELEC 1SNA165909R0500 Screwless rail contact
Part Number # 1SNA165909R0500
SKU # 2344906

1SNA165909R0500
ENTRELEC 1SNA165909R0500 Screwless rail contact
Part Number # 1SNA165909R0500
SKU # 2344906
ENTRELEC 1SNA165909R0500 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNA165909R0500 |
| SKU #: | 2344906 |
| Dimensions: | 50.7 mm H x 5 mm W x 40.5 mm L |
| Type: | D2.5/5.P |
| UNSPSC: | 39121410 |
| UPC: | 00662019960470 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Prices are in USD. Orders shipped to Canada may be subject to duties, taxes and brokerage fees, collected by the carrier on delivery.
ENTRELEC 1SNA165909R0500 Screwless rail contact
Brand: ENTRELEC
Part Number: 1SNA165909R0500
TE Connectivity, 1SNA165909R0500, TE Connectivityrminal Block, D2.5/5.P, Series: SNA, 3.5 kV, 300 A, 2 Pole, 12 AWG Wire, 10 mm Wire Strip Length, 5 mm Spacing, 0.4 N-m Torque, DIN Rail Mounting, Screw Clamp Connection, -55 to 110 deg C, Polyamide, Green/Yellow, 50.7 mm H x 5 mm W x 40.5 mm L Dimensions
Additional Description: TEC -1SNA165909R0500 D2.5/5.P Screw Clamp Terminal Blocks - Ground - Green/Yellow 016590905
Catalog Description: - Screwless rail contact, - Reliable electrical and mechanical contact with the rail.
1SNA165909R0500 Application
For Signal1SNA165909R0500 Item Features
- Screw clamp, stud technologies
- Available functions are feed-through, ground, disconnect, fuse, single to triple deck, test & measurement
- Power stud range available with stud-stud or stud-screw clamp technologies
- Ease the identification of functions inside cabinet thanks to large range of coloured variants
- The SNA connection technologies eliminate the need for retightening campaigns thanks dedicated anti-release system
- Avoid mounting and wiring errors thanks to asymmetrical design
- Allow installation flexibility with extra mounting options such as TS32 rail,panel or plate
- 50% faster assembly time thanks to the locking pin, 10 pre-assembled blocks plugged-in on rail at a time
- Elimination of faulty manouvers thanks to screw type jumper bars
1SNA165909R0500 Standards
UL 94V-0|EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|China RoHS 2 Directive MIIT Order No 32, 2016|EU REACH Regulation (EC) No. 1907/2006|PROP65SKU #2344906Part Number #1SNA165909R0500UNSPSC39121410UPC00662019960470
Image provided may only be a representation of final product and may include optional equipment
