Part Number # 1SNA199105R2200
SKU # 970692
Image Disclaimers Message
1SNA199105R2200
ENTRELEC 1SNA199105R2200 Simplify the disconnect operations for the disconnect terminal blocks installed next to fuse terminal blocks ML10/13.SF...
Part Number # 1SNA199105R2200
SKU # 970692
ENTRELEC 1SNA199105R2200 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNA199105R2200 |
| SKU #: | 970692 |
| Amperage Rating: | 16 A |
| Dimensions: | 85 mm H x 13 mm W x 58 mm L |
| Number of Poles: | 2 |
| Series: | SNA |
| Spacing: | 13 mm |
| Temperature Rating (Degrees F): | -55 to 110 deg C |
| Terminal Type: | Clamp |
| Torque Rating: | 1.2 N-m |
| Type: | ML10/13.SN |
| Wire Size: | 10 AWG |
| Color: | Black |
| Connection type: | Screw |
| Country of origin: | PL |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00662019016955 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ENTRELEC 1SNA199105R2200 Simplify the disconnect operations for the disconnect terminal blocks installed next to fuse terminal blocks ML10/13.SF...
Brand: ENTRELEC
Part Number: 1SNA199105R2200
TE, 1SNA199105R2200, Terminal Blocks, ML10/13.SN, Series: SNA, 800 V, 16 A, 2 Pole, 10 AWG Wire, 12 mm Wire Strip Length, Clamp Terminal, 13 mm Spacing, 1.2 N-m Torque, DIN Rail Mounting, Screw Connection, -55 to 110?| deg C, Polyamide, Black, 85 mm H x 13 mm W x 58 mm L Dimensions
Additional Description: TEC -1SNA199105R2200 (N) ML10/13.SN Screw Clamp Terminal Blocks - Disconnect with lever - Black, Blue NON-CANCELABLE, NON-RETURNABLE NON-CANCELABLE, NON-RETURNABLE 019910522 NON-CANCELABLE, NON-RETURNABLE
Catalog Description: - Simplify the disconnect operations for the disconnect terminal blocks installed next to fuse terminal blocks ML10/13.SF..., - With the same profile as ML10/13.SF, the ML10/13.SN disconnect lever is easily operated by hand and the wiring of the alternated disconnect and fuse circuits is easier, - Link bar for lever included in terminal block.
1SNA199105R2200 Application
For Signal1SNA199105R2200 Includes
Link bar1SNA199105R2200 Item Features
- Screw clamp, stud technologies
- Available functions are feed-through, ground, disconnect, fuse, single to triple deck, test & measurement
- Power stud range available with stud-stud or stud-screw clamp technologies
- Ease the identification of functions inside cabinet thanks to large range of coloured variants
- The SNA connection technologies eliminate the need for retightening campaigns thanks dedicated anti-release system
- Avoid mounting and wiring errors thanks to asymmetrical design
- Allow installation flexibility with extra mounting options such as TS32 rail,panel or plate
- 50% faster assembly time thanks to the locking pin, 10 pre-assembled blocks plugged-in on rail at a time
- Elimination of faulty manouvers thanks to screw type jumper bars
1SNA199105R2200 Standards
UL 94V-0|EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|China RoHS 2 Directive MIIT Order No 32, 2016|EU REACH Regulation (EC) No. 1907/2006|PROP65SKU #970692Part Number #1SNA199105R2200UNSPSC39121410UPC00662019016955
