Part Number # 1SNK505061R0000
SKU # 2221808
Image Disclaimers Message
Brand: ENTRELEC
1SNK505061R0000
ENTRELEC 1SNK505061R0000 Save space by connecting conductors up to 4 mm (without insulated ferrule
Part Number # 1SNK505061R0000
SKU # 2221808
$45.00 / 50Each
Typical price:$58.00 / Each
ENTRELEC 1SNK505061R0000 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNK505061R0000 |
| SKU #: | 2221808 |
| Amperage Rating: | 20, 20 A, 32 A |
| Dimensions: | 2.09 in L x 0.205 in W x 1.92 in H, 53 mm H x 5.2 mm W x 47.3 mm L |
| Number of Poles: | 2 |
| Series: | SNK |
| Spacing: | 5.2, 5.2 mm |
| Temperature Rating (Degrees F): | -55 to 110, -55 to 110 deg C |
| Terminal Type: | Clamp, Feed-Through |
| Type: | ZS4-GN |
| Wire Size: | 12 AWG, 12 AWG Stranded |
| Color: | Green |
| Connection type: | Screw, Screw Clamp |
| Country of origin: | FR |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | ABB, TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00804325488075 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$45.00 / 50Each
Typical price:$58.00 / Each
Quantity:
- ABB entrelec Terminal Block, Series: SNK, 600 VAC, 20 A, 12 AWG Stranded Wire, 10.5 mm Wire Strip Length, Feed-Through Terminal, 5.2 mm Spacing, DIN Rail Mount, Screw Clamp, -55 to 110 deg C, Polyamide, Green, 2.09 in L x 0.205 in W x 1.92 in H
1SNK505061R0000 Application
For applications ranging from standard distribution and control panels, to specialized applications in key industries such as traction, energy, maritime, explosive atmospheres and material handling1SNK505061R0000 Item Features
- Easy and ergonomic mounting, unique profile
- Marking surfaces can be read clearly from any angle in an enclosure and are larger than standard markers
- 600 VAC main circuit voltage, 1 W power loss
- Use with applications ranging from standard distribution and control panels
- Mounting on DIN rail TH35-7.5 (35 x 7.5 mm mounting rail) according to IEC 60715 - TH35-15 (35 x 15 mm mounting rail) according to IEC 60715
- IP20 deg of protection
- Extended product type ZS4 - GN
- Flexible 24 to 12 AWG, flexible (2) 24 to 16 AWG, rigid 24 to 12 AWG, rigid (2) 24 to 16 AWG, with insulated ferrule 24 to 14 AWG, without insulated ferrule 24 to 12 AWG, with twin ferrule 24 to 16 AWG
- Save space by connecting conductors up to 12 AWG in just 0.205 in spacing
1SNK505061R0000 Standards
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ATEX Approved|cUL Listed|BV|CB|CE Certified|CSA Certified|DNV|RINA CertifiedSKU #2221808Part Number #1SNK505061R0000UNSPSC39121410UPC00804325488075
