Part Number # 1SNK706012R0000
SKU # 2281909
Image provided may only be a representation of
final product and may include optional equipment
1SNK706012R0000
ENTRELEC 1SNK706012R0000 Find all the features of the ZK4 terminal block with the added option of distributing or branching 4 conductors.
Part Number # 1SNK706012R0000
SKU # 2281909
ENTRELEC 1SNK706012R0000 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNK706012R0000 |
| SKU #: | 2281909 |
| Amperage Rating: | 32 A |
| Dimensions: | 89.7 mm H x 6 mm W x 41.1 mm L |
| Number of Poles: | 4 |
| Series: | SNK |
| Spacing: | 6 mm |
| Temperature Rating (Degrees F): | -55 to 110 deg C |
| Type: | ZK4-4P |
| Wire Size: | 10 AWG |
| Connection type: | PI Spring |
| Country of origin: | FR |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00888614180536 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ENTRELEC 1SNK706012R0000 Find all the features of the ZK4 terminal block with the added option of distributing or branching 4 conductors.
Brand: ENTRELEC
Part Number: 1SNK706012R0000
TE, 1SNK706012R0000, Terminal Blocks, ZK4-4P, Series: SNK, 1000 V, 32 A, 4 Pole, 10 AWG Wire, 12.5 mm Wire Strip Length, 6 mm Spacing, DIN Rail Mounting, PI Spring Connection, -55 to 110?| deg C, Polyamide, Gray, 89.7 mm H x 6 mm W x 41.1 mm L Dimensions
Additional Description: TEC -1SNK706012R0000 ZK4-4P PI-Spring clamp Terminal Block - Feed-through - Grey 1SNK706012R0000
Catalog Description: Find all the features of the ZK4 terminal block with the added option of distributing or branching 4 conductors.
1SNK706012R0000 Item Features
- Screw is locked in total safety
- Maintenance and trouble shooting operations are minimized thanks to our anti-release system
- High density capacity screw clamp connection can fit up to two conductors per clamp which offers extended possibilities in electrical cabinets
- 50% faster assembly time thanks to the locking pin
- 10 pre-assembled blocks plugged-in on rail at a time
- Excellent marker visibility thanks to the exclusive top marking location
- Save installation time with our snap on screwless ground terminal blocks,end stops, plugs and jumpers
- Reliable hardened steel clamp
- Convenient double central channels allow multiconfigurations like jumpering, testing and measuring
- Time and stock saving with plug-in insulated jumpers, cuttable and available up to 50 poles
- Flat marking surface allows the use of marker cards, labels or pre-marking by hand
- Ready for new utility-scale photovoltaic installations with ZS150 / ZS240 screw clamp terminal blocks going up to 1500 V DC (IEC) and 1000 V DC (UL)
- Circuit identification is improved thanks to the 20% larger marking area
- Pre-mark by hand or with label on our flat marking surface and start immediately the wiring, before the final markers mounting
1SNK706012R0000 Standards
UL 94V-0|IP20|EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|China RoHS 2 Directive MIIT Order No 32, 2016|EU REACH Regulation (EC) No. 1907/2006|PROP65SKU #2281909Part Number #1SNK706012R0000UNSPSC39121410UPC00888614180536
