Part Number # 1SNK708010R0000
SKU # 2281906
Image Disclaimers Message
1SNK708010R0000
ENTRELEC 1SNK708010R0000 Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL
Part Number # 1SNK708010R0000
SKU # 2281906
$48.00 / 50Each
Typical price:$61.60 / Each
ENTRELEC 1SNK708010R0000 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNK708010R0000 |
| SKU #: | 2281906 |
| Amperage Rating: | 41, 41 A |
| Dimensions: | 41.9 mm L x 8 mm W x 57.5 mm H, 57.5 mm H x 8 mm W x 41.9 mm L |
| Number of Poles: | 2 |
| Series: | SNK |
| Spacing: | 8, 8 mm |
| Temperature Rating (Degrees F): | -55 to 110, -55 to 110 deg C |
| Terminal Type: | Feed-Through |
| Type: | ZK6 |
| Wire Size: | 8, 8 AWG |
| Color: | Gray |
| Connection type: | PI Spring, Spring |
| Country of origin: | FR |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | ABB, TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00888614180574 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$48.00 / 50Each
Typical price:$61.60 / Each
Quantity:
- TE Connectivity, 1SNK708010R0000, TE Connectivityrminal Block, ZK6, Series: SNK, 1 kV, 41 A, 2 Pole, 8 AWG Wire, 12.5 mm Wire Strip Length, 8 mm Spacing, DIN Rail Mounting, PI Spring Connection, -55 to 110 deg C, Polyamide, Gray, 57.5 mm H x 8 mm W x 41.9 mm L Dimensions
1SNK708010R0000 Item Features
- Screw is locked in total safety
- Maintenance and trouble shooting operations are minimized thanks to our anti-release system
- High density capacity screw clamp connection can fit up to two conductors per clamp which offers extended possibilities in electrical cabinets
- 50% faster assembly time thanks to the locking pin
- 10 pre-assembled blocks plugged-in on rail at a time
- Excellent marker visibility thanks to the exclusive top marking location
- Save installation time with our snap on screwless ground terminal blocks,end stops, plugs and jumpers
- Reliable hardened steel clamp
- Convenient double central channels allow multiconfigurations like jumpering, testing and measuring
- Time and stock saving with plug-in insulated jumpers, cuttable and available up to 50 poles
- Flat marking surface allows the use of marker cards, labels or pre-marking by hand
- Ready for new utility-scale photovoltaic installations with ZS150 / ZS240 screw clamp terminal blocks going up to 1500 V DC (IEC) and 1000 V DC (UL)
- Circuit identification is improved thanks to the 20% larger marking area
- Pre-mark by hand or with label on our flat marking surface and start immediately the wiring, before the final markers mounting
1SNK708010R0000 Standards
UL 94V-0|IP20|EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|China RoHS 2 Directive MIIT Order No 32, 2016|EU REACH Regulation (EC) No. 1907/2006|PROP65SKU #2281906Part Number #1SNK708010R0000UNSPSC39121410UPC00888614180574
