Part Number # 1SNK900403R0000
SKU # 2319552
Image Disclaimers Message
1SNK900403R0000
ENTRELEC 1SNK900403R0000 Component holder compatible with 5.2 mm 0.205 in spacing ZS4 feed-through terminal blocks
Part Number # 1SNK900403R0000
SKU # 2319552
ENTRELEC 1SNK900403R0000 Key Features
| Brand: | ENTRELEC |
|---|---|
| Part Number # : | 1SNK900403R0000 |
| SKU #: | 2319552 |
| Dimensions: | 37.9 mm H x 10 mm W x 48.9 mm L |
| Series: | PG5-R2 |
| Suitable For Use With: | ZDP2-5-11/ZDP2-5-22/ZK2-5/ZK2-5-3P/ZK2-5-4P/ZK2-5-D2/ZK2-5-D-CH/ZP2-5/ZP2-5-3P/ZP2-5-4P/ZP2-5-D2/ZS4/ZS4-D2/ZS4-D-CH/ZS4-R2/ZS4-T3/ZS4-T3-R1 |
| Type: | Low Voltage |
| Color: | Dark Grey |
| Country of origin: | FR |
| Material: | Polyamide |
| Manufacturer Name: | TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00804325489546 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ENTRELEC 1SNK900403R0000 Component holder compatible with 5.2 mm 0.205 in spacing ZS4 feed-through terminal blocks
Brand: ENTRELEC
Part Number: 1SNK900403R0000
PG5-R2 Component Plug - Dark Grey
Additional Description: TEC -1SNK900403R0000 (N) PG5-R2 Component Plug - Dark Grey 1SNK900403R0000 NON-CANCELABLE, NON-RETURNABLE
Catalog Description: - Component holder compatible with 5.2 mm 0.205 in spacing ZS4 feed-through terminal blocks, - Fit components 16 x 16 x 8.5 mm 0.630 x 0.630 x 0.335 in (not supplied with plug) such as resistors, diodes, varistance, - Direct plug-in into the terminal blocks jumper channels, - Maximum dissipatived power: 2 W.
1SNK900403R0000 Item Features
- Screw is locked in total safety
- Maintenance and trouble shooting operations are minimized thanks to our anti-release system
- High density capacity screw clamp connection can fit up to two conductors per clamp which offers extended possibilities in electrical cabinets
- 50% faster assembly time thanks to the locking pin
- 10 pre-assembled blocks plugged-in on rail at a time
- Excellent marker visibility thanks to the exclusive top marking location
- Save installation time with our snap on screwless ground terminal blocks,end stops, plugs and jumpers
- Reliable hardened steel clamp
- Convenient double central channels allow multiconfigurations like jumpering, testing and measuring
- Time and stock saving with plug-in insulated jumpers, cuttable and available up to 50 poles
- Flat marking surface allows the use of marker cards, labels or pre-marking by hand
- Ready for new utility-scale photovoltaic installations with ZS150 / ZS240 screw clamp terminal blocks going up to 1500 V DC (IEC) and 1000 V DC (UL)
- Circuit identification is improved thanks to the 20% larger marking area
- Pre-mark by hand or with label on our flat marking surface and start immediately the wiring, before the final markers mounting
1SNK900403R0000 Standards
IP20 Standards|IEC Certified|EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|China RoHS 2 Directive MIIT Order No 32, 2016|Solder Process Capability|EU REACH Regulation (EC) No. 1907/2006SKU #2319552Part Number #1SNK900403R0000UNSPSC39121410UPC00804325489546
