Brand: Finder
391070249024
FINDER 391070249024 Solid State Relay
Part Number # 391070249024
SKU # 2263017
$230.40 / 10Each
Typical price:$321.60 / Each
Finder 391070249024 Key Features
| Brand: | Finder |
|---|---|
| Part Number # : | 391070249024 |
| SKU #: | 2263017 |
| Contact Configuration: | 1NO SPST, 1NO/SPST |
| Dimensions: | 6.2 mm W x 87 mm H |
| Release time: | 0.6 ms |
| Series: | MasterBASIC 39 Series |
| Specifications: | 5 A Rated Current, 24 V DC Coil and 1 mA Minimum Switching Current, 5 A Rated Current, 24 VDC Coil and 1 mA Minimum Switching Current |
| Type: | Solid State |
| Manufacturer Name: | FINDER |
| UNSPSC: | 39122333 |
| UPC: | 08012823353623 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$230.40 / 10Each
Typical price:$321.60 / Each
Quantity:
- Finder Relay Interface Module, Solid State, Series: MasterBASIC 39 Series, 1NO SPST Contact Configuration, 0.2 ms Operate, 0.6 ms Release Time, Specifications: 5 A Rated Current, 24 V DC Coil and 1 mA Minimum Switching Current, 6.2 mm W x 87 mm H Dimensions
391070249024 Application
Labelling Machine, Bottling Plant, Carousel Warehouse, Control Panel, Hoist, Crane, Packaging Machine and Traffic Light Control Applications391070249024 Item Features
- Common connection of terminals A1, A2 and 13 with the jumper link
- https://www.findernet.com/en/usa/video/39-series-all-products-and-accessories/
391070249024 Standards
CE Certified|cRUus Listed|EAC Compliant|EN 60715|HazLoc Class I Division 2 Group A, B, C, D - T5 - T6|RoHS Compliant|UKCA Compliant|UL ListedSKU #2263017Part Number #391070249024UNSPSC39122333UPC08012823353623
