Part Number # P-XX-K3RD0
SKU # 2362243
Image Disclaimers Message
Brand: Grace Technologies
P-XX-K3RD0
Grace Engineered Products P-XX-K3RD0 Ethernet Port Connector
Part Number # P-XX-K3RD0
SKU # 2362243
$208.38 / Each
Typical price:$215.00 / Each
Grace Technologies P-XX-K3RD0 Key Features
| Brand: | Grace Technologies |
|---|---|
| Part Number # : | P-XX-K3RD0 |
| SKU #: | 2362243 |
| Type: | Type 4 |
| Mounting type: | Panel |
| UNSPSC: | 32151708 |
| UPC: | 00842864102519 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$208.38 / Each
Typical price:$215.00 / Each
Quantity:
Grace Engineered Products P-XX-K3RD0 Ethernet Port Connector
Brand: Grace Engineered Products
Part Number: P-XX-K3RD0
GracePorts Ethernet Port Connector, Type 4, Panel Mounting
Additional Description: GRAC-P-XX-K3RD0 N12/4 PANEL MOUNT, 120 VAC DUP LEX OUTLET TYPE 4, DUPLEX OUTLET Point,CST AL Base,Polycarbonate CVR
Catalog Description: PANEL INTERFACE CONNECTOR, PMH, UL TYPE 4, DUPLEX OUTLET
P-XX-K3RD0 Item Features
- IP65 enclosure rating
- Size K housing
- Low voltage (data), limited to 30 VDC
- High voltage supply (for computer use only) 120 VAC, 15A (UL), 5A (CSA) , 230 to 240 VAC, 16A (CE only)
- Cast aluminum base housing
- Type 304 stainless steel latch (1CR18NI19)
- Polycarbonate, UV rated, V-O flame rated cover
- Thermoplastic elastomer gasket
- Acrylic UL94 HB insert
- RJ45 F/F bulkhead connector
- NEMA 12/4 rated housing
- ThruView housing
- 3.54 in H x 5.08 in W x 1.6 in D
SKU #2362243Part Number #P-XX-K3RD0UNSPSC32151708UPC00842864102519
