Part Number # DTS3181A460N4SS
SKU # 2450296
Image Disclaimers Message
DTS3181A460N4SS
Hammond Manufacturing DTS3181A460N4SS
Part Number # DTS3181A460N4SS
SKU # 2450296
$5015.64 / Each
Typical price:$6179.27 / Each
Hammond Manufacturing DTS3181A460N4SS Key Features
| Brand: | Hammond Manufacturing |
|---|---|
| Part Number # : | DTS3181A460N4SS |
| SKU #: | 2450296 |
| Amperage Rating: | 2 to 15 A |
| Control Type: | Thermostat |
| Dimensions: | 29.46 in H x 15.55 in W x 11.5 in D |
| Enclosure Type: | NEMA 3R/4/4X/IP56, NEMA 3R/4/IP56 |
| Frequency Rating: | 50/60 Hz |
| Series: | DTS Series |
| Temperature Rating (Degrees F): | 32 to 131 deg F Ambient |
| Connection type: | Drain Hose/Clamp |
| Country of origin: | US |
| Material: | Galvanized Steel |
| Mounting type: | Side |
| Manufacturer Name: | Hammond Manufacturing |
| UNSPSC: | 40101701 |
| UPC: | 00062398001047 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$5015.64 / Each
Typical price:$6179.27 / Each
Quantity:
- Hammond Air Conditioner, Series: DTS Series, 460 V AC, 2 to 15 A, 1200 W, 50/60 Hz, 4100 Btu/hr Capacity, NEMA 3R/4/4X/IP56, Thermostat Control, Drain Hose/Clamp, 32 to 131 deg F Ambient, Side Mount, Galvanized Steel, 304 Stainless Steel, 29.46 in H x 15.55 in W x 11.5 in D
DTS3181A460N4SS Application
Outdoor ApplicationsDTS3181A460N4SS Includes
Gasket, Mounting Kit and TemplateDTS3181A460N4SS Item Features
- R134a refrigerant
- Thermostat control accessible from inside enclosure
- Expansion valve prevents evaporator freeze up while minimizing heavy inrush currents on large Btu/hr units
- Built in condensate evaporator
- Continuous air circulation from high capacity fans
- EMI/RFI suppression meets CE
- Self-diagnostics on startup
- Fault indication via LED light
- Provision for door contact allowing power down when enclosure door is opened
- Gasket, mounting kit and template for enclosure cutout and drilling are included
- NEMA 4 exterior 304 stainless steel
- Optimum air circulation with maximum clearance distance between warm inlet and cold outlet for reduced hot spot locations
- Closed loop cooling ensures clean enclosure air is recirculated without ever mixing with contaminated ambient air
- Designed for side mounting on any enclosure surface where high capacity system cooling is required
DTS3181A460N4SS Standards
RoHS Compliant|UL Listed|cUL Listed|cULus Listed|CE Certified|eccn: EAR99DTS3181A460N4SS Warranty
1 yearSKU #2450296Part Number #DTS3181A460N4SSUNSPSC40101701UPC00062398001047
