- Appealing style with a flush, smooth profile and satin finish to complement any decor
- All distracting stepped surfaces on face, including lights and conspicuous text, have been eliminated
- Clear indication if unit can no longer provide protection (LED red flashes) and will not reset
- Patented tamper-resistant mechanism designed specifically for residential applications
- Autoguard self-test technology with auto-monitor, power denial
- Provides ease of insertion
Specifications
Brand: Hubbell
Amperage Rating: 15 A
Dimensions: 1.75 in W x 1.47 in D x 4.12 in H
Horsepower: 1 hp
NEMA Rating: 5-15R, NEMA 5-15R
Number of Poles: 2
Number of Wires: 3
Temperature Rating (Degrees F): -30 to 150 deg F
Terminal Type: Screw
Type: Grounding Tamper Resistant Weather Resistant, Tamper/Weather-Resistant
Voltage Rating: 125 VAC
Color: Light Almond
Country of origin: CN
Material: Composite/Thermoplastic
Manufacturer Name: Hubbell
UNSPSC: 39121406
UPC: 00883778450846
Item FeaturesKitchens, Bathrooms, Garages, Basements, Laundry Areas, Workshops, Wet or Damp Locations, Outdoor Porches and Deck Applications
Item Features
Item FeaturesANSI C73|UL 498/943 File No. E41978|UL94 V2 Flammability Rating|CSA C22.2 No. 42/M-012A|NEMA WD1/WD5/WD6|NEC 406.12, 517-18c, 406.9|NOM Certified
