Brand: Hubbell
Hubbell HBL13R23 HBL Switched Disconnects and Enclosures, 600 VAC, 30 A, 20 hp, 3 Poles
Image Disclaimers Message
Brand: Hubbell
Hubbell HBL13R23 HBL Switched Disconnects and Enclosures, 600 VAC, 30 A, 20 hp, 3 Poles
Brand: Hubbell
Hubbell HBL13R23 HBL Switched Disconnects and Enclosures, 600 VAC, 30 A, 20 hp, 3 Poles
Part #:HBL13R23
SKU #: 2410397
$128.14/EA
Key Features
Part #:HBL13R23
SKU #: 2410397
Brand: Hubbell
Amperage Rating: 30 A
Dimensions: 4.55 in H x 2.99 in W x 5.42 in L
Enclosure Type: NEMA 3/3R
Horsepower: 20 hp
Number of Poles: 3
$128.14/EA
- https://players.brightcove.net/2519281010001/S1rfC16yx_default/index.html?videoId=6357119734112
Specifications
Brand: Hubbell
Amperage Rating: 30 A
Dimensions: 4.55 in H x 2.99 in W x 5.42 in L
Enclosure Type: NEMA 3/3R
Horsepower: 20 hp
Number of Poles: 3
Phase: 3
Series: HBL
Short Circuit Current Rating (kA): 60 A
Temperature Rating (Degrees F): -40 to 75 deg C
Terminal Type: Pressure Screw
Type: Disconnect Switch
Voltage Rating: 600 VAC
Color: Gray
Country of origin: CN, US
Mounting type: Screw
Manufacturer Name: Hubbell
UNSPSC: 39121521
UPC: 00783585680965
Hubbell HBL13R23 HBL Switched Disconnects and Enclosures, 600 VAC, 30 A, 20 hp, 3 Poles
Additional Description: HUBW-HBL13R23 30A 600V 3 POLE PLASTIC 3R W/SW
Catalog Description: Circuit-Lock® NEMA 3/3R Enclosure Switch Disconnect, 3-Pole, 30A 600V AC, Thermoplastic
Item FeaturesFor Red Handle
Item Features
Item FeaturesCSA-C22.2 No.14|Industrial Control File LR-46186|UL 508|Industrial Control File E70402
