Part Number # HBL2321
SKU # 98250
HBL2321
Hubbell HBL2321 Locking Plug
Part Number # HBL2321
SKU # 98250
Hubbell HBL2321 Key Features
| Brand: | Hubbell |
|---|---|
| Part Number # : | HBL2321 |
| SKU #: | 98250 |
| Cord Diameter: | 0.36 to 0.93 in |
| Dimensions: | 2.26 x 2.26 x 2.75 in |
| Enclosure: | IP20 |
| Horsepower: | 2 hp |
| NEMA Rating: | L6-20P |
| Number of Wires: | 3 |
| Series: | HBL |
| Temperature Rating (Degrees F): | -40 to 75 deg C |
| Type: | 1-Phase Grounding Cord Mount |
| Material: | Nylon |
| Manufacturer Name: | Hubbell |
| UNSPSC: | 39121402 |
| UPC: | 00783585037820 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Hubbell HBL2321 Locking Plug
Brand: Hubbell
Part Number: HBL2321
Wiring Device-Kellems Twist-Lock Insulgrip Locking Plug, 1-Phase Grounding Cord Mount, 250 VAC, 20 A, 2 hp, 2 Pole, 3 Wires, L6-20P NEMA Rating, Industrial Grade, IP20 Enclosure, 0.36 to 0.93 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Black/White, 2.26 x 2.26 x 2.75 in
Additional Description: HUBW-HBL2321 LKG PLUG, 20A 250V, L6-20P, B/W 20A 250V
Catalog Description: Locking Devices, Twist-Lock®, Industrial, Male Insulgrip® Plug, 20A 250V AC, 2-Pole 3-Wire Grounding, NEMA L6-20P, Screw Terminal, Black and White Nylon.
HBL2321 Application
Power Connection ApplicationsHBL2321 Item Features
- Integral dust shield protects wiring chamber from dust or contaminants
- Clear, funnel shaped wire entry for ease of termination
- Ribbed nylon housing provides a secure grip and impact and chemical resistance
- Superior cord grip design protects terminations from excess strain
- https://youtu.be/1DnPJu3QNw0
HBL2321 Standards
NEMA WD1/WD5|UL 498|UL94 Flammability Rating|Federal Specification W-C-596|CSA C22.2 No. 42/0.6|RoHS CompliantSKU #98250Part Number #HBL2321UNSPSC39121402UPC00783585037820
Image provided may only be a representation of final product and may include optional equipment
